1988 Honda ZB50’88 bike     Engine Engine Type 49cc OHC single cylinder YTX4L BS – 12 volt DRIVETRAIN Transmission 3-speed with an automatic clutch CHASSIS / SUSPENSION / BRAKES N/A DIMENSION N/A OTHER Colors black with Max Silver Metallic Fuel tank black Fenders black Fork legs black Frame silver Swing arm silver Seat red …

1985 Elite 250 (CH250) Engine Engine Type Type: 4-stroke liquid-cooled Cylinders One Displacement 244cc DRIVETRAIN N/A CHASSIS / SUSPENSION / BRAKES N/A DIMENSION N/A OTHER Seat color Black with maroon seating surface Front fender emblem HONDA” is an outline Colors Candy Orchid Red Summer Blond Metallic V.I.N JH2MF010_FK000001 ~ Engine MF01E-5000001 ~ 1986 Elite 250 …

2004 CBF500 ABS Engine Type Liquid-cooled 4-stroke 8-valve parallel twin cylinder Bore and Stroke 73 x 59.6 mm Fuel Delivery 34mm slanted flat-slide VP- type carburetor x 2 Displacement 499cc Compression Ratio 10.5:1 Max. Power Output 56 bhp at 9500 rpm Max. Torque 45 Nm at 8000 rpm Ignition Computer-controlled digital system Starter Electric Transmission …

2012 Honda Integra 670 OVERVIEW The Integra takes its name from the fact it integrates the ease of use of a scooter with the dynamic performance of a motorcycle. It has a feet-forward riding position, protection from the elements, internal storage and the advanced three-mode transmission in the shape of the second generation of Honda’s …

1969-70 CB750K0 Four It was available in one of three colors: Candy Blue Green Candy Gold Candy Ruby Red The tank, side covers, and upper forks were of the basic color (green, gold, or red) The headlight shell was also the basic color The bike had a 4-into-4 throttle cable system The exhaust system was …

1970-71 Honda C70M (also called C70MK0 or CM70) Engine Engine Type 72cc OHC single cylinder Spark plug C7HSA Plug gap .028 Battery 6YB11-2D or 6N11-2D DRIVETRAIN Transmission 3-speed with an automatic clutch CHASSIS / SUSPENSION / BRAKES N/A DIMENSION N/A OTHER Like the early cub, this model did not significantly look any different Colors: Aquarius …

1959-66 Hawk 250 (CB72) Engine Engine Type 247cc 4-stroke OHC parallel twin with two carburetors DRIVETRAIN Transmission 4-speed CHASSIS / SUSPENSION / BRAKES N/A DIMENSION N/A OTHER Color Blue with Silver Scarlet Red with Silver Black with Silver The fuel tank, fork covers, headlight shell, and frame were painted the basic color The fenders and …

1962-63 Honda Trail 55 C105T Engine Engine Type 54cc 4-stroke OHV single cylinder DRIVETRAIN Transmission three-speed with automatic clutch CHASSIS / SUSPENSION / BRAKES N/A DIMENSION N/A OTHER Colors Scarlet Red Yellow The exhaust was down-swept (unlike the CA105T) The seat was a solo seat with chrome trim; but larger than the Trail 50 The …

Chaly 50 (CF50)   Engine Engine air cooled single cylinder 4 cycles Displacement 49cc Bore & Stroke 39.0mm × 41.4mm Compression ratio 10.0:1 Carburetor VC 58 Starting system Kick system Ignition device type CDI type magnetic ignition Lubricating system Force splash combined use system DRIVETRAIN Clutch type Wet multiple plate coil spring system Transmission type …

2007 S-Wing 125 Engine Engine Type Liquid-cooled 4-stroke SOHC single Displacement 125cm3 Bore and Stroke 52.4 x 57.8mm Compression Ratio 11:1 Carburation PGM-FI electronic fuel injection Fuel Delivery 26mm VK-type Ignition Digital transistorised with electronic advance Max. Power Output 9.7kW/9,000min-1 (95/1/EC) Max. Torque 11.1Nm/7,500min-1 (95/1/EC) Starter Electric DRIVETRAIN Transmission V-Matic Final Drive V-belt Front Wheel …

1979 CX500C’79 Custom Colors: Candy Plum Red Candy Universal Blue The pinstripes were gold The “CX500 CUSTOM” side cover decal was gold The front forks were the straight axle type The mirrors had a flat bas with thin, angled stalks The speedometer had a 120 mph (195 kph) limit The engine was a 496cc OHV …

1997 CBR1100XX’97 ENGINE N/A DRIVETRAIN N/A CHASSIS / SUSPENSION / BRAKES N/A DIMENSION N/A OTHER It was available in one color: Mute Black Metallic The engine was a light weight 1137cc inline four cylinder where the upper crankcase and cylinder block were one piece The braking system was linked The serial number began JH2SC350*VM000001. 2000 …

1996 Honda Hornet 250 Engine Engine Type Liquid cooled, four stroke, Transverse four cylinder, DOHC, 4 valve per cylinder. Displacement 249cc Bore and Stroke 48.5 x 33.8 mm Compression Ratio 11.5:1 Max Power 40 hp 29.2 kW @ 14000 rpm Max Torque 24 Nm @ 11000 rpm DRIVETRAIN Transmission 6-speed Final drive Chain CHASSIS / …

1979 CX500D’79 DELUXE It came in one color: Candy Presto Red The pinstripes were gold The “CX500 DELUXE” side cover emblem was also gold The speedometer had a 120 mph (195 kph) limit The engine was a 496cc OHV liquid-cooled V-twin linked to a 5-speed transmission and a shaft drive The serial number began PC01-400005 …

1967-69 CL125A Scrambler 125 Engine Engine Type OHC twin cylinder Displacement 124cc Fuel delivery Single CV carburetor DRIVETRAIN Transmission 4-speed CHASSIS / SUSPENSION / BRAKES N/A DIMENSION N/A OTHER Color Candy Blue with Metallic Silver Candy Red with Metallic Silver Bright Yellow with Metallic Silver Black with Metallic Silver The frame and upper forks were …

1988 Interceptor VTR250’88 (VTR250L’88 in California) Engine Engine Type 4-stroke liquid-cooled DOHC V-twin cylinders Displacement 249cc DRIVETRAIN Transmission 6-speed CHASSIS / SUSPENSION / BRAKES N/A DIMENSION Front Tire pressure: 32 psi (221 KPa) Rear Tire pressure: 36 psi (248 KPa) OTHER Color Black with Brad Blue Ross White with Brad Blue The black bike had …

1982 CX500tc’82 500 Turbo NGINE N/A DRIVETRAIN N/A CHASSIS / SUSPENSION / BRAKES N/A DIMENSION N/A OTHER It came in one color scheme: Pearl Altair White with Moonstone Silver Metallic The body stripes were Day-Glo red, dark gray, and light gray The “CX500” decal was Day-Glo red The speedometer had a 85 mph (135 kph) …

2003 Metropolitan II (CHF 50P) Engine Engine 49cc liquid-cooled single-cylinder four-stroke Fuel Delivery 15.0mm CV with automatic choke Spark plug CR8EH-9 Plug gap .036 Ignition CDI DRIVETRAIN Transmission Automatic V-Matic belt drive CHASSIS / SUSPENSION / BRAKES Front Suspension Twin-downtube fork; 1.9-inch travel Rear Suspension Single shock; 2.6-inch travel Front Brake Drum Rear Brake Drum …

1983 Honda CR60R’83 Engine Engine Type 58cc 2-stroke reed valve single cylinder Carburetor 22mm (a larger one came the following year) Spark plug BR9ES Plug gap .028 DRIVETRAIN Transmission six speeds Chain #420 x 104 Front sprocket 14 T Rear sprocket 45 T CHASSIS / SUSPENSION / BRAKES N/A DIMENSION N/A OTHER In previous years, …

1979 Honda Z50R’79 Mini Trail bike Engine Engine he tired OHV engine of the Z50A was replaced with a stronger 49cc OHC single cylinder Ignition points Exhaust pipe went to the left side of the bike rather than on the right Spark plug C6HSA Plug gap .028 DRIVETRAIN Transmission 3-speed with an automatic clutch Chain …

1984 GL1200 For 1984 the 1100cc model was replaced by a larger 1200cc engine   Colors Black Candy Wineberry Red The headlight was round with a chrome shell The taillight assembly was free-standing and had a ribbed lens.   Engine 1182cc opposed four cylinder SOHC liquid-cooled Valve Hydraulic Valve Adjuster system Transmission 5-speed Drive Shaft …

2004 Varadero XL1000V Engine Engine Type Liquid-cooled 4-stroke 8-valve DOHC 90° V-twin Displacement 996cc Bore and Stroke 98 x 66mm Compression ratio 9.8 :1 Fuel Delivery PGM-FI electronic fuel injection Max. Power Output 93 bhp at 8,000 rpm Max. Torque 98Nm at 6,000 rpm Ignition Computer-controlled digital transistorised with electronic advance and HISS Starting system …

2002 Honda Magna 250   Engine Displacement 249cc Type Four-stroke DOHC V-2 cylinder Bore & Stroke 60.0 x 44.1 mm Compression 11.0:1 Valving 4 valves per cylinder Cooling Liquid Power 19.7 kW (27.0 HP) @ 10000 rpm Torque 23.0 Nm (17 ft.lb) @ 7500 rpm Fuel delivery Carburetor DRIVETRAIN Transmission 5-speed with a manual clutch …

1959-62 Honda C100 Super Cub 50 Engine Engine 49cc OHV single cylinder Starter only a kick starter Spark plug C7HSA Plug gap .024 Battery 6N2-2A — 6 volt DRIVETRAIN Transmission 3-speed with an automatic clutch CHASSIS / SUSPENSION / BRAKES N/A DIMENSION N/A OTHER Colors Scarlet Red with White White Blue with White Black with …

1983 VF750F’83 V45 Interceptor Engine Engine Type Liquid-cooled in-line 90° V-4 Displacement 748cc (45 cid) Bore And Stroke 70mm x 48.6mm Compression Ratio 10.5:1 Valve Train 16-valve DOHC Fuel Delivery Four 32mm integrated dual-draft type carburetors Power 86 horsepower Cooling Liquid-cooling system using two slim-line radiators Exhaust system Two-into-two Ignition system Transistorized pointless with electronic …

1967 Honda C65 “Cub 65” ENGINE Engine: 63cc OHC single cylinder DRIVETRAIN N/A CHASSIS / SUSPENSION / BRAKES N/A DIMENSION N/A OTHER Sold in Canada

1976 MR250’76 Elsinore Engine Engine Type 2-stroke piston port single cylinder Displacement 248cc DRIVETRAIN Transmission 5-speed CHASSIS / SUSPENSION / BRAKES N/A DIMENSION N/A OTHER Color Light Ruby Red with White The gas tank and side covers were red The tank contained 3.4 US gallons (12.9 liters) The fenders were white, color-impregnated plastic The headlight …

2004 SH125 Engine Engine Type Liquid-cooled 4-stroke SOHC single Displacement 125cc Bore and Stroke 52.4 x 57.8mm Compression Ratio 11.0 :1 Fuel Delivery 26mm VK-type Ignition DC CDI Max. Power Output 10.1kW/9000min-1 (95/1/EC) Max. Torque 11.5Nm/7000min-1 (95/1/EC) Starter Electric DRIVETRAIN Transmission V-Matic Final Drive Belt drive Front Wheel 16 x MT2.50 cast aluminum Rear Wheel …

1980 GL1100I’80 Engine Engine Type Liquid-cooled four cylinder horizontally opposed OHC Displacement 1085 cc Bore and Stroke 75 x 61.4 mm Compression ratio 9.2:1 Fuel Delivery four 30 mm, CV type Valves 2 valves/cylinder Exhaust system Four-into-two with balance tube Ignition system Transistorized pointless Starting system electric Fuel type regular gasoline Horsepower 81 hp (60.4 …

1965-69 Honda “Sport 65” Engine Engine Type 63cc OHC single cylinder Spark plug C7HSA Plug gap .028 Battery 6N2A-2C-3 — 6 volt DRIVETRAIN Transmission 4-speed with manual clutch CHASSIS / SUSPENSION / BRAKES N/A DIMENSION N/A OTHER Colors White Black Scarlet Red Model ID S65 or CS65 Fuel tank emblem red with silver wing Seat …

1989 VFR750 RJ 1990 VFR750R’90 RC30 It was available in one color scheme: Ross White with Wistaria Blue, Seychell Blue, and Red The bike had twin round headlights There was a single-sided swingarm The exhaust system was stainless steel The engine had titanium connecting rods The engine was a 748cc DOHC 16 valve liquid-cooled V-4 …

1998 VT1100T ACE Tourer 1100 (American Classic Edition Tourer Hard saddle bags and windshield (standard equipment) Exhaust was specially designed 2-into-2 system Colors: Black Black with Pearl Ivory Cream Pearl Jade Green with Pearl Ivory Cream Pearl Sedona Red with Black Model designation: VT1100T (California designation: VT1100TL) Serial number began: 1HFSC370*WA000001 (Calif: 1HFSC371*WA000001) Engine serial …

CD70   Engine Engine Type 72cc 4-stroke OHC single cylinder DRIVETRAIN Transmission 4-speed with manual clutch CHASSIS / SUSPENSION / BRAKES N/A DIMENSION N/A Weight 80 kg (176 lb) OTHER 188 mpg (US) 188 mpg (US) Max speed 85 km/h (53 mph)

CF70 Chaly ENGINE N/A DRIVETRAIN Tire: 3.50-10 CHASSIS / SUSPENSION / BRAKES N/A DIMENSION N/A OTHER CF70 Image Gallery

2004 Shadow VT125C Engine Engine Type Liquid-cooled 4-stroke 4-valve SOHC 90° V-twin Displacement 125cc Bore and Stroke 42 x 45mm Compression Ratio 11.8:1 Fuel Delivery 22mm VP-type x 2 Ignition Digital transistorised with electronic advance Max. Power Output 15 bhp at 11,000 rpm Max. Torque 10.5Nm at 9,000 rpm DRIVETRAIN Transmission 5-speed Final Drive Roller …

2008 DN-01 Engine Engine Type 680cc liquid-cooled fuel-injected 8-valve V-twin engine Liquid-cooled 4-stroke 8-valve SOHC 52° Vtwin Displacement 680cc DRIVETRAIN Clutch Automatic, HFT with internal hydraulic control CHASSIS / SUSPENSION / BRAKES Front Tire 130/70 ZR17M/C (62W) Rear Tire 190/50 ZR17M/C (73W) DIMENSION Fuel capacity 17 litres (including 3-litre LCD-indicated reserve) Dimensions 2,315 x 820 x …

1971 SL125K0 ENGINE N/A DRIVETRAIN N/A CHASSIS / SUSPENSION / BRAKES N/A DIMENSION N/A OTHER Colors: Candy Emerald Green Strato Blue Metallic Poppy Yellow Metallic On the green bikes, the tank stripe was white; but on the other colors, it was black The steel fenders are painted The tachometer was standard The bike had a …

1982 VF750S’82 V45 Sabre Engine Engine Type Liquid-cooled in-line V-4 Displacement 748cc Bore And Stroke 70mm x 48.6mm Compression Ratio 10.5:1 Valve Train 16-valve DOHC Fuel Delivery Four 32mm integrated dual-draft type carburetors Exhaust system Two-into-two Ignition system Transistorized ;plointless with electronic advance Starting system Electric Fuel type Regular gasoline DRIVETRAIN Transmission Six-speed including overdrive …

2004 CRF70F Engine Engine Type 72cc air-cooled single-cylinder four-stroke Valve Train SOHC; two-valve Bore and Stroke 47.0mm x 41.4mm Compression Ratio 9.0:1 Fuel Delivery 13.0mm piston-valve Ignition CDI Spark plug CR6HSA Plug gap .028 DRIVETRAIN Transmission Three-speed with automatic clutch Final Drive #420 chain; 15T/36T CHASSIS / SUSPENSION / BRAKES Front Suspension 27.0mm telescopic fork; …
