Posts in category

Parallel Twin


1978-79CB400N2 Engine Engine Air cooled, parallel twin cylinder, four stroke, SOHC, 3 valves per cylinder, 360° crankshaft and twin balance-shafts Displacement 395cc Bore x Stroke 70.5 x 50.6 mm Compression Ratio 9.3:1 Fuel Delivery Four 32mm Keihin carburetors Ignition CDI Max Power 26.7 hp @ 7500 rpm Max Torque 24.5 ft-lb @ 8000 rpm Drivetrain …

1975 CB360T0 Engine Engine Air cooled, parallel twin cylinder, SOHC, 2 valve per cylinder, Displacement 357cc Bore x Stroke 67.0 x 50.6 mm Compression Ratio 9.3:1 Fuel Delivery 2 CV carburetors Ignition Breaker points and condenser Starter Electric and kickstart Max Power 24.8 KW (34 hp) @ 9000 rpm Drivetrain Transmission 6-speed Final Drive Chain …

1978 Hawk Hondamatic (CB400A’78) Engine Engine Air cooled, parallel twin cylinder, SOHC, 3 valve per cylinder Displacement 395cc Bore x Stroke 70.5 x 50.6mm Compression Ratio 9.3:1 Fuel Delivery Two 32mm Keihin CV carburetors Ignition CDI Starter Electric Max Power 26.8 HP @ 8000 rpm Max Torque 21.39 lb-ft @ 5000 rpm Drivetrain Transmission 2-speed …

1997 Honda CB500S Engine Engine Type Liquid cooled, parallel twin cylinder, four stroke, DOHC, 4 valve per cylinder Displacement 494cc (30.1 cid) Bore and Stroke 73 x 59 mm Compression Ratio 10.5:1 Fuel Delivery Two 32mm Keihin CV Ignition CDI Starter Electric Max Power 58 hp 42.3 kW @ 9500 rpm Max Torque 47 Nm …

1974 CB360K0 Engine Engine Air cooled, parallel twin cylinder, SOHC, 2 valve per cylinder Displacement 357cc Bore x Stroke 67.0 x 50.6 mm Compression Ratio 9.3:1 Fuel Delivery 2 CV carburetors Ignition Breaker points and condenser Starter Electric and kickstart Max Power 24.8 KW (34 hp) @ 9000 rpm Drivetrain Transmission 6-speed Final Drive Chain …

1974 CL360K0 It came in one color: Muscat Green Metallic The gas tank stripes were black The mufflers were black with chrome heat shield The “CL360” side cover emblem was yellow and white The engine was a 356cc OHC parallel twin linked to a 6-speed transmission The serial number began CL360-1000001. 1975 CL360K1 It came …

1976 CJ360T’76 Engine Engine Air cooled, parallel twin cylinder, SOHC, 2 valve per cylinder, Displacement 357cc Bore x Stroke 67.0 x 50.6 mm Compression Ratio 9.3:1 Fuel Delivery 2 CV carburetors Ignition Breaker points and condenser Starter Electric and kickstart Max Power 24.8 KW (34 hp) @ 9000 rpm Drivetrain Transmission 6-speed Final Drive Chain …

1974 CB360G Engine Engine Air cooled, parallel twin cylinder, SOHC, 2 valve per cylinder, Displacement 357cc Bore x Stroke 67.0 x 50.6 mm Compression Ratio 9.3:1 Fuel Delivery 2 CV carburetors Ignition Breaker points and condenser Starter Electric and kickstart Max Power 24.8 KW (34 hp) @ 9000 rpm Drivetrain Transmission 6-speed Final Drive Chain …

1982 Honda Custom CM250C’82 Engine Engine Type Type: OHC parallel twin cylinder Displacement 234cc DRIVETRAIN N/A CHASSIS / SUSPENSION / BRAKES N/A DIMENSION N/A OTHER Color Candy Muse Red with Candy Antares Red Cosmo Black Metallic with Gray Metallic The tank and side covers are two-toned The “CM250 CUSTOM” side cover decal was gold The …

1968 Honda Super Sport 250 (CB250K0) Engine Engine Type 249cc Air cooled, four stroke, twin parallel cylinders, SOHC Bore And Stroke 56 x 50.6 mm Compression Ratio 9.5:1 Fuel Delivery Two CV Valve Train 2 per cylinder Max Power 30 hp 21.9 kW @ 10500 rpm DRIVETRAIN Transmission 5-speed Final Drive Chain CHASSIS / SUSPENSION …

1962-65 Scrambler 250 CL72 Engine Engine Type 4-stroke OHC parallel twin cylinders Displacement D8EA247cc Fuel delivery two carburetors DRIVETRAIN Transmission 4-speed CHASSIS / SUSPENSION / BRAKES N/A DIMENSION N/A OTHER Color Blue with Silver Scarlet Red with Silver Black with Silver The headlight shell, frame, upper fork covers, fork legs, and shock covers were painted …

1959-60 Honda Dream Touring 250 C71 Engine Engine Type Air-cooled, parallel twin with a dry sump and SOHC Displacement 247.3cc Bore and Stroke 54 x 54 mm Compression Ratio 6.2:1 Ignition 6-volt magnetic flywheel Starter Kick start Max Power 13.3 KW/ 18 hp @ 7400 rpm DRIVETRAIN Transmission 4-speed Clutch Wet multi-plates Final Drive Chain …

1980 Honda Super Hawk 250 Engine Engine Type Air cooled, four stroke, parallel twin cylinder, OHC Displacement 249cc Bore and Stroke 62 x 41.4 mm Compression Ratio 9.4:1 Fuel Delivery 29mm Mikuni carb Ignition Capacitor discharger (CDI) Max Power 27 hp @ 10000 rpm Max Torque 14.7 ft-lb @ 8500 rpm DRIVETRAIN Transmission 6-speed Final …

2004 CBF500 ABS Engine Type Liquid-cooled 4-stroke 8-valve parallel twin cylinder Bore and Stroke 73 x 59.6 mm Fuel Delivery 34mm slanted flat-slide VP- type carburetor x 2 Displacement 499cc Compression Ratio 10.5:1 Max. Power Output 56 bhp at 9500 rpm Max. Torque 45 Nm at 8000 rpm Ignition Computer-controlled digital system Starter Electric Transmission …

2012 Honda Integra 670 OVERVIEW The Integra takes its name from the fact it integrates the ease of use of a scooter with the dynamic performance of a motorcycle. It has a feet-forward riding position, protection from the elements, internal storage and the advanced three-mode transmission in the shape of the second generation of Honda’s …

1959-66 Hawk 250 (CB72) Engine Engine Type 247cc 4-stroke OHC parallel twin with two carburetors DRIVETRAIN Transmission 4-speed CHASSIS / SUSPENSION / BRAKES N/A DIMENSION N/A OTHER Color Blue with Silver Scarlet Red with Silver Black with Silver The fuel tank, fork covers, headlight shell, and frame were painted the basic color The fenders and …

2012 Honda NC700S Engine Engine Type Liquid-cooled 4-stroke 8-valve, SOHC parallel 2-cylinder Bore and Stroke 73 x 80mm Valves Chain driven SOHC, 4 valves per cylinder Displacement 670cc Compression Ratio 10.7:1 Fuel Delivery PGM-FI electronic fuel injection Max. Power Output 35kW/6,250min-1 (95/1/EC) Max. Torque 60Nm/4,750min-1 (95/1/EC) Starter Electric DRIVETRAIN Transmission 6-speed, Final Drive O-ring sealed …

1965-66 CB450K0 Engine Engine Type Air cooled, parallel twin cylinder, four stroke, DOHC, 2 valves per cylinder, Displacement 445cc (27 cu. in.) Bore and Stroke 70 x 57.8 mm Compression Ratio 9.0:1 Fuel Delivery Dual CV Carburetors Ignition Points and condenser Starter N/A Max Power 45 hp @ 9000 rpm Max Torque 4 kg-m @ …

2012 Honda NC700X Engine Engine Type Liquid-cooled 4-stroke 8-valve, SOHC parallel 2-cylinder Bore and Stroke 73 x 80mm Valves Chain driven SOHC, 4 valves per cylinder Displacement 670cc Compression Ratio 10.7:1 Fuel Delivery PGM-FI electronic fuel injection, 36mm throttle body Ignition System Computer-controlled digital transistorised with electronic advance Throttle Bore 36mm Starter Electric Max. Torque …

1969 CB125 Engine Engine Type Air cooled, twin cylinder, OHC Displacement 124cc Bore and Stroke 44 X 41mm Compression Ratio 9.4:1 Fuel Delivery 26mm Keihin Carbs, manual choke DRIVETRAIN Transmission 5-speed Final Drive Chain CHASSIS / SUSPENSION / BRAKES Front Brakes Drum Rear Brakes Drum Front Tire 2.50-18 Rear Tire 2.75-18 DIMENSION Dry-Weight 133 kg …

1980 CB400T’80 HAWK OVERVIEW Honda fielded two 400 Hawks: in 1978 and 1979 (possibly earlier) a basic Hawk (called Hawk I CB400Ti) had drum front brakes, wire spoke wheels, and just a speedo in 1976 to 1979 a more expensive Hawk (called Hawk II CB400Tii) had disc front brakes, Comstar wheels, and both speedo and tach In …

1984 Honda Rebel 250 CM250C’84 Engine Engine Type 234cc OHC, Parallel Twin Bore And Stroke 53 x 53 mm Compression Ratio 9.4:1 Carburetor 26 mm with accelerator pump Valve Train Ignition CDI with electronic advance Starter electric Max Power Max Torque DRIVETRAIN Transmission Five-speed, constant mesh Drive line Polyurethane/Aramid fibre belt The belt is quiet, …

1974-75 500 Twin DOHC (CB500T0) Engine Engine Type Air cooled, parallel twin cylinder, four stroke, DOHC, 2 valves per cylinder, Bore and Stroke 70.0 x 64.8 mm Ignition Breaker points and condenser Displacement 499cc (30.4 cid) Compression Ratio 8.5:1 Fuel Delivery Dual CV Keihin Carburetors Max. Power Output 42 hp 30.7 KW @ 8000 rpm …

1991 Honda Nighthawk CB250’91 (CB250L’91 in California) Engine Engine Type 234cc Air cooled, four stroke, twin cylinder Bore And Stroke 53 x 53 mm Compression Ratio 9.2:1 Fuel Delivery 22mm Keihin carb Valve Train Ignition CDI Starter Electric Max Power 20 hp 14.6 kW @ 9000 rpm Max Torque 18 Nm @ 6500 rpm DRIVETRAIN …

1976 Honda CB400Tii Engine Engine Type Air cooled, parallel twin cylinder, four stroke, SOHC, 360° crankshaft and twin balance-shafts Valving 3 valves per cylinder Displacement 395cc Bore and Stroke 70.5 x 50.6mm Compression Ratio 9.3:1 Fuel Delivery Two 32mm Keihin carburetors Ignition CDI Starter Electric Max Power 26.8 HP @ 8000 rpm Max Torque 21.39 …

1959-60 Dream Touring 300 C76 Colors: White Black Blue Scarlet Red The handlebars were low-rise, pressed steel and painted The fuel tank is one of the four basic colors with a solid chrome plate, but no rubber knee pad It had a square headlight with an integrated speedometer The engine was a 305cc 4-stroke OHC …

1961-68 Honda Super Hawk 305 (CB77) Engine Engine Type Air cooled, four stroke, parallel twin cylinder SOHC Displacement 305cc Bore and Stroke 60 x 54 mm Compression Ratio 9.5:1 Carburetors Twin Starter Kickstart Max Power 16.8 KW (23.8 hp) @ 7500 rpm Max Torque 23.1 NM @ 6000 rpm DRIVETRAIN Transmission 4-speed Clutch Wet multi-plate …

1965-68 Scrambler 305 (CL77) Colors: Blue Red Black The fuel tank, side covers, and fenders were silver The frame, upper fork, and headlight shell were painted one of the basic colors The fuel tank had a rubber knee pad The two exhaust pipes were mounted on the left side and converged into a single muffler …

2000 CB600F Hornet Engine Type Liquid-cooled 4-stroke, Bore and Stroke 65 x 45.2mm Displacement  599cc Compression Ratio 12:1 Carburation Four 34mm downdraft flat-slide CV-type Max. Power Output [email protected],750rpm Max. Torque 45lb/[email protected],250rpm Ignition Computer-controlled digital transistorized with electronic advance Starter Electric Gearbox 6-speed Final Drive ‘O’-ring sealed chain Dimensions 2095 x 740 x 1065mm Wheelbase 1425mm …

1969-70 Motosport 350 (SL350K0) Colors: Candy Sapphire Blue Candy Ruby Red Candy Gold The fuel tank stripe was white The frame had a single downtube It had both a electric and kick starter The engine was a 325cc 4-stroke OHC parallel twin with two CV carburetors The transmission was a 5-speed The front wheel was …

1982 CM450A-82 Hondamatic Colors: Candy Muse Red with Candy Antares Red Candy Empire Blue with Candy Dark Blue The gas tank and side covers were two-tone The “CM450A HONDAMATIC” side cover decal was gold The comstar wheels were highlighted black The speedometer had a 85 mph (135 kph) limit The engine was a 447cc SOHC …

1968-69 CL350K0 Colors: Daytona Orange with White Candy Red with White Candy Blue with White The gas tank was a two-tone The upper forks were black in the early model and the basic color (orange, red, or blue) in later models The side covers and headlight shell were white The seat was not pleated The …

1992 Honda CB450DX Engine Engine Type Air cooled, parallel twin cylinder, four stroke, SOHC, 3 valves per cylinder Displacement 447cc (27 cu. in.) Bore and Stroke 75 X 50.6 mm Compression Ratio 9.1:1 Fuel Delivery Two 30mm Keihin CV Ignition CDI Starter Electric Max Power 43.3 hp @ 8500 rpm Max Torque 4.3Kgm 42.1Nm @ …

1987 Honda CB450S Engine Engine Type Air cooled, parallel twin cylinder, four stroke, SOHC, 3 valves per cylinder, 360� crankshaft and twin balance-shafts Displacement 447cc (27 cid) Bore and Stroke 75 X 50.6mm Compression Ratio 9.1:1 Fuel Delivery Two 30mm Keihin CV Ignition CDI Starter Electric Max Power 45 hp 32.8 KW @ 9000 rpm …

1982 CB450T’82 Engine Engine Type Air cooled, parallel twin cylinder, four stroke, SOHC, 3 valves per cylinder, 360� crankshaft and twin balance-shafts Displacement 447cc (27 cid) Bore and Stroke 75 X 50.6mm Compression Ratio 9.1:1 Fuel Delivery Two 30mm Keihin CV Ignition CDI Starter Electric Max Power 45 hp 32.8 KW @ 9000 rpm Drivetrain …

2004 CBF600S Engine Engine Type Inline 4 Cylinder, liquid-cooled 4-stroke 16-valve DOHC Bore and Stroke 65 x 45.2mm Displacement 600cc Compression Ratio 10.7:1 Fuel Delivery 34mm slanted flat-slide VP- type carburetors x 4 Max. Power Output 76 bhp at 10,500 rpm Max. Torque 58Nm at 8000 rpm Ignition Computer controlled digital system Starter Electric DRIVETRAIN …

1982 CM450E-82 Colors: Candy Muse Red Candy Imperial Blue The “CM450E” side cover decal was gold The wheel had wire spokes The front brakes were mechanical drum There was no tachometer — only a speedometer with a 85 mph (135 kph) limit The engine color was silver The engine was a 447cc SOHC 3-valve parallel …

1982 CM450C-82 Custom It came in one of two color schemes: Candy Muse Red with Candy Antares Red and Candy Empire Blue with Candy Dark Blue The gas tank and side covers were 2-toned The “CM450 CUSTOM” side cover decal was gold The comstar wheels were highlighted black The speedometer had a 85 mph (135 …

1982 CB450T’82 Colors: Pleiades Silver Metallic Black The stripes on the black bike were orange and red while on the silver bike they were black and blue The engine color was black The engine was a 447cc SOHC 3-valve parallel twin with a 6-speed transmission The serial number began JH2PC050*CM000011.

1982 Nighthawk 450 (CB450SC’82) Engine Engine Type Air cooled, four stroke, parallel twin cylinder, SOHC, 2 valves per cylinder, Displacement 447cc (27 cu. in.) Bore and Stroke 75 X 50.6mm Compression Ratio 9.1:1 Fuel Delivery Two 34mm constant velocity Ignition Solid state Starter Electric Max Power 45 hp 32.8 KW @ 9000 rpm Drivetrain Transmission …
