1974 XL125K0 Engine Engine Type OHC single cylinder Displacement 122cc Cylinder head One piece unit DRIVETRAIN Transmission 5-speed CHASSIS / SUSPENSION / BRAKES N/A DIMENSION N/A OTHER Color Fire Red with Silver Metallic and Black The gas tank was red; the muffler heat shield and side covers were black The fenders were silver painted plastic …

1980 CB400T’80 HAWK OVERVIEW Honda fielded two 400 Hawks: in 1978 and 1979 (possibly earlier) a basic Hawk (called Hawk I CB400Ti) had drum front brakes, wire spoke wheels, and just a speedo in 1976 to 1979 a more expensive Hawk (called Hawk II CB400Tii) had disc front brakes, Comstar wheels, and both speedo and tach In …

Honda CRF70F Motorcycles Engine Engine Type 72cc air-cooled single-cylinder four-stroke Valve Train SOHC; two-valve Bore and Stroke 72cc air-cooled single-cylinder four-stroke Compression Ratio 9.0:1 Fuel Delivery 13.0mm piston-valve Ignition CDI Spark plug CR6HSA Plug gap .028 DRIVETRAIN Transmission Three-speed with automatic clutch Final Drive #420 chain; 15T/36T CHASSIS / SUSPENSION / BRAKES Front Suspension 27.0mm …

20029 Honda CB400SS Engine Engine Air cooled, four stroke, single cylinder, OHC, 4 valve, Displacement 397cc Bore x Stroke 85 x 70 mm Compression Ratio 8.8:1 Max Power 29 hp 21.2 KW @ 7000 rpm Max Torque 31 Nm @ 5500 rpm Drivetrain Transmission 5-speed Final Drive Chain CHASSIS / SUSPENSION / BRAKES Front Brakes …

2008 VTX1300T Overview: We weren’t about to let the VTX1800 family have all the touring fun, so allow us to introduce the all-new VTX1300T. Built with the same purpose as its VTX1800T sibling, complete with large touring windshield, spacious leather saddlebags and handy passenger backrest, the VTX1300T is the perfect choice for riders seeking big …

1977 Honda NC50’77 Express Engine Engine 49cc 2-stroke single cylinder. The engine was lubricated by oil injection. Spark plug BP4HS Plug gap .028 Battery 6N4-2A-6 (see also 6N4-2A-8) — 6 volt The starting system used a wind-up spring. The ignition was controlled by breaker points. It also had a manual choke. DRIVETRAIN Transmission one speed. …

1983 XL125R   Engine Engine Type 124 cc, 4-Stroke, Air Cooled, Single Bore and Stroke 56.5 mm x 49.5 mm Valves OHC, 2 valves/cylinder Ignition System Contactless type CDI Horsepower 12 hp (8.9 kW) @ 9000 rpm Maximum Torque 10 Nm (7.4 ft. lbs) @ 8000 rpm DRIVETRAIN Transmission 6 speed Final Drive Chain CHASSIS …

2007 NT700V Deauville Engine Engine Type Liquid-cooled 4-stroke 8-valve SOHC 52° V-twin Engine Displacement 680.2cc Bore and Stroke 81 x 66cm Valves 10 :1 Carburation PGM-FI electronic fuel injection Max. Power Output 48.3 kW/8,000 min (95/1/EC) (65bhp) Max. Torque 66.2 Nm/6,500 min (95/1/EC) Ignition Digital transistorised with electronic advance DRIVETRAIN Transmission  5 speed Final Drive …

2004 CRF230F Engine Type 223cc air-cooled single-cylinder four-stroke Bore and Stroke 65.5mm x 66.2mm Compression Ratio 9.0:1 Valve Train SOHC; two-valve Fuel Delivery 26mm piston-valve Ignition CDI Transmission Six-speed Final Drive #520 O-ring-sealed chain; 13T/50T Front Suspension 37mm leading-axle Showa fork; 9.5-inch travel Rear Suspension Pro-Link Showa single-shock with spring-preload adjustability; 9.0-inch travel Front Brake …

1979 Honda NA50’79 Express II Engine Engine 49cc 2-stroke single cylinder with oil injection It also had a wind-up spring starting system, points ignition, and manual choke. Spark plug BP4HS Plug gap .028 Battery 6N4-2A-6 (see also 6N4-2A-8) — 6 volt DRIVETRAIN Transmission one-speed automatic transmission. CHASSIS / SUSPENSION / BRAKES It had twin chrome …

1969-71 Trail 70 (CT70K0) Engine Engine Type 72cc OHC single cylinder Spark plug C7HSA Plug gap .028 Battery 6N5.5-1D — 6 volt DRIVETRAIN Transmission 3-speed with automatic clutch Chain #420 x 86 Front sproket 15 T 35 T CHASSIS / SUSPENSION / BRAKES N/A DIMENSION N/A OTHER Colors andy Ruby Red Candy Gold Candy Sapphire …

2004 XR125L Engine Engine Type Air-cooled 4-stroke OHV single Displacement 124cc Bore and Stroke 56.5 x 49.5mm Compression Ratio 9.5 :1 Max. Power Output 8.3kW/8500min-1 (95/1/EC) Max. Torque 10Nm/7000min-1 (95/1/EC) Fuel Delivery 22mm PD-type carburetor Ignition Digital transistorised with electronic advance Starter Electric DRIVETRAIN Transmission 5-speed Final Drive Roller chain Front Wheel 19 x MT1.85 …

1998 Honda X-Four   Engine Engine Type Liquid cooled, four stroke, transverse four cylinders, Displacement 1284cc Bore and Stroke 78 x 67.2 mm Compression Ratio   9.6:1 Starter Electric Max Power 100 hp 72.9 kW @ 6500 rpm Max Torque 121 Nm @ 5000 rpm DRIVETRAIN     Transmission 5-speed Final drive Chain CHASSIS / …

1959-63 CA95 Benly Touring 150 (early model) Engine Engine Type OHC parallel twin Displacement 154cc Carburetor Single DRIVETRAIN Transmission 4-speed CHASSIS / SUSPENSION / BRAKES DIMENSION N/A OTHER Color Black Scarlet Red Blue White The headlight was square with an integrated speedometer The fuel tank had small rubber knee pads and a large chrome panel …

1970-71 Trail 70 (CT70HK0) (also called “Mini Trail 70”) Engine Engine Type 72cc OHC single cylinder Spark plug C7HSA Plug gap .028 Battery 6N2A-2C DRIVETRAIN Transmission 4-speed with a manual clutch Chain #420 x 86 Front sprocket 15 T Rear sprocket 35 T CHASSIS / SUSPENSION / BRAKES N/A DIMENSION N/A OTHER Colors Candy Blue …

2003 CRF150F Engine Type 156.8cc air-cooled single-cylinder four-stroke Bore and Stroke 63.5mm x 49.5mm Compression Ratio 9.0:1 Valve Train SOHC; two-valve Fuel Delivery 24mm piston-valve Ignition CDI Transmission Five-speed Final Drive #520 O-ring-sealed chain; 13T/48T Front Suspension 35mm leading-axle Showa fork; 9.1-inch travel Rear Suspension Pro-Link Showa single-shock; 8.8-inch travel Front Brake Single 240mm disc …

1982 XL250R’82 Engine Engine Type 249cc OHC 4-valve single cylinder with two exhaust pipes Spark plug DR8ES-L Plug gap 028 Electricals 12-volt electrical system Battery YB3L-A — 12 volt DRIVETRAIN Transmission 6-speed Clutch #520 x 102 Front sprocket 14 T Rear sprocket 47 T CHASSIS / SUSPENSION / BRAKES Rear Suspension Pro-Link suspension Front wheel …

1981 XR200R’81 Engine Engine Type OHC, 2-valve, single cylinder Displacement 195cc DRIVETRAIN Transmission 6-speed CHASSIS / SUSPENSION / BRAKES Rear suspension Pro-LinkTM DIMENSION N/A OTHER It was sold alongside the XR200’81 Color: just one color: Tahitian Red The black “XR” decal was located just forward of the black number plate panel The headlight cowl was …

1984 GYRO 50 NN50MD OVERVIEW It had two rear wheels and pivoting-link frame to let the front part lean during cornering while rear power unit stays flat   Engine Engine Type two-stroke air cooled single Oil supply oil injection Displacement 49cc Compression ratio 7.2:1 Fuel Delivery 14mm piston-valve type Spark plug BPR6HS Plug gap .028 …

1969 Honda CL70 “Scrambler 70” Engine Engine Type 72cc OHC single cylinder Spark plug C7HSA Plug gap .028 Battery 6N5.5-1D-1 which is discontinued, modify 6N5.5-1D to fit DRIVETRAIN Transmission 4-speed with manual clutch CHASSIS / SUSPENSION / BRAKES N/A DIMENSION N/A OTHER Followed the pattern for all Scramblers: slightly raised handlebars, exhaust pipe upswept just …

1971-72 Honda SL70 K0 Motosport Engine Engine Type 72cc OHC single cylinder Spark plug C7HSA Plug gap .028 Battery 6N2A-2C — 6 volt DRIVETRAIN Transmission 4-speed with manual clutch CHASSIS / SUSPENSION / BRAKES N/A DIMENSION N/A OTHER In 1974 it was called the XL70 although it was basically the same bike as the SL70 …

1974 Honda XL70K0 Engine Engine Type 72cc OHC single cylinder Spark plug C7HSA Plug gap .028 Battery 6N4C-1B — 6 volt DRIVETRAIN Transmission 4-speed with manual clutch Drive chain #420 x 96 Front sprocket 13 T Rear sprocket 44 T CHASSIS / SUSPENSION / BRAKES N/A DIMENSION N/A OTHER Colors Candy Topaz Orange The “HONDA” …

1968 CB125 ENGINE Engine Type: 122cc OHC single cylinder with a one-piece cylinder head The ignition used breaker points DRIVETRAIN N/A CHASSIS / SUSPENSION / BRAKES N/A DIMENSION N/A OTHER Similar to the 1968 CB175 Knee pads on the fuel tank Wing and “HONDA” are on the upper half of the tank Side cover is …

1972-73 Motosport 250 XL250 Engine Engine Type 248cc 4-stroke OHC 4-valve single cylinder Spark plug D8EA Plug gap 028 Battery 6N6-3B — 6 volt DRIVETRAIN Transmission 5-speed Clutch Hydraulic Front sprocket 15 T Rear sprocket 48 T CHASSIS / SUSPENSION / BRAKES N/A DIMENSION N/A OTHER One color was available: Custom Silver Metallic The fuel …

1997 XR70R’97 Engine Engine Type 70cc Spark plug CR6HSA Plug gap .028 DRIVETRAIN Drive chain #420 x 86 Front sprocket 14 T Rear sprocket 49 T CHASSIS / SUSPENSION / BRAKES N/A DIMENSION N/A OTHER A new off road model (i.e., no headlight or mirrors, etc.) Available color: Shasta White Serial number began: JH2DE020*VK000001. 1998 …

Honda CB125SS Engine Engine Type Air cooled, twin cylinder, OHC, 2 valve per cylinder Displacement 124cc Bore and Stroke 44 X 41mm Compression Ratio 9.4:1 Fuel Delivery 2x Keihin 22mm slide type Max. Power Output 15 hp @ 11000 rpm Max. Torque 1.05 kg-m @ 9000 rpm Starter Electric DRIVETRAIN Transmission 5-speed Final Drive Chain …

1977 Honda XL75’77 Engine Engine Type 75cc OHC single cylinder Spark plug C7HSA Plug gap .028 Battery 6N4C-1B — 6 volt DRIVETRAIN Drive chain 4-speed with manual clutch Chain #420 x 94 Front sprocket 14 T ear sprocket 36 T CHASSIS / SUSPENSION / BRAKES N/A DIMENSION N/A OTHER Colors Tahitian Red Fuel tank stripe …

2012 Honda CBF125 Engine Engine Type Air-cooled 4-stroke 2-valve OHC single Displacement 124.7cc Bore and Stroke 52.4 x 57.8mm Compression Ratio 9.2:1 Fuel Delivery PGM-FI electronic fuel injection Ignition Computer controlled fully transistorised with electronic advance Max. Power Output 8.3kW/8,000min-1 Max. Torque 11.2Nm/6,250min-1 Starter Electric DRIVETRAIN Transmission 5-speed Final Drive 2.63 Front Wheel U-cross-section 6-spoke …

1984 CR500R’84 It descended from a long line of Elsinores, although it was not called by that name It was sold in 1984 One color was available: Flash Red The number plate panels were yellow, the seat was blue, the fork boots were black, and the wheel rims were silver It used a round-slide carburetor …

1979 CR125R’79 Elsinore Engine Engine Type 2-stroke reed valve single cylinder Displacement 124cc DRIVETRAIN Transmission 6-speed Front wheel 23 in. Rear wheel 18 in. CHASSIS / SUSPENSION / BRAKES N/A DIMENSION N/A OTHER Color: Tahitian Red The engine was red; but the shock springs were black The fork boots were black The serial number began …

1982 VT250F Engine Engine Type Two cylinder 90° V Twin, Four stroke Displacement 248 cc Bore and Stroke 60 mm x 44 mm Compression Ratio 11:1 Valvetrain DOHC, 4 valves per cylinder Ignition System Transistor contactless system Maximum power 26.1 kW (35 hp) @ 11,000 rpm Maximum torque 21.5 N·m (15.9 lb·ft) @ 10,000 rpm …

1971 500 Four (CB500K0) Engine Engine Ty Air cooled, transverse four cylinder, four stroke, SOHC, 2 valve per cylinder. Bore and Stroke 56.0 x 50.6 mm Ignition Breaker points and condenser Displacement 498cc (30.4 cid) Compression Ratio 9.0:1 Fuel Delivery Four 22mm Keihin Carburetors Max. Power Output 48 hp 35 KW @ 9000 rpm Starter …

2004 CBR125R Engine Engine Type Liquid-cooled 4-stroke 2-valve SOHC single Displacement 124.7cc Bore and Stroke 58 x 47.2mm Compression Ratio 11 :1 Fuel Delivery VK-type carburetor Ignition Capacitor Discharge (CDI) Max. Power Output 13 bhp at 10,000 rpm Max. Torque 10.1Nm at 8000 rpm Starter Electric DRIVETRAIN Transmission 6 speed Final Drive O-ring sealed chain …

2004 CRF50F Engine Engine 49cc air-cooled single-cylinder four-stroke Bore & Stroke 39.0mm x 41.4mm Compression ratio 10.0:1 Spark plug CR6HSA Plug gap .028 Valve Train SOHC; two-valve Fuel Delivery 13.0mm piston-valve Ignition CDI DRIVETRAIN Transmission Three-speed with automatic clutch Final Drive #420 chain; 14T/37T CHASSIS / SUSPENSION / BRAKES Tire size 3.50-10-2 PR (front and …

1973 Honda XR75K0 Engine Engine Type 72cc OHC single cylinder Spark plug C7HSA Plug gap .028 DRIVETRAIN Transmission 4-speed with manual clutch Chain #420 x 100 Front sprocket 14 T Rear sprocket 44 T CHASSIS / SUSPENSION / BRAKES N/A DIMENSION N/A OTHER Available color: Rubber Gray Metallic The “HONDA” fuel tank decal and top …

1984 Interceptor 500 (VF500F’84) It was designated VF500FL’84 in California Two color schemes were available: Candy Alamoana Red with Black and Shasta White, and Candy Aleutian Blue with Fighting Red and Shasta White The wheels were machined finish with black spokes The seat and front legs were black The front fender was white The 4-into-2 …

2001 VT1100C’01 SHADOW SPIRIT 1100 Engine Engine Type Liquid cooled, 45° V-twin, dual offset pin crank Engine Displacement 1099cc Bore and Stroke 87.5mm x 91.4mm Compression Ratio 8:1 Valve Train SOHC, 3 valve per cylinder, self-adjusting hydraulic Fuel Delivery Twin 36mm, diaphragm-type CV Drivetrain Transmission Wide-Ratio, 5-speed Final Drive Shaft CHASSIS / SUSPENSION / BRAKES …

1974 CG125 ENGINE N/A DRIVETRAIN N/A CHASSIS / SUSPENSION / BRAKES N/A DIMENSION N/A OTHER It was not sold in the USA or Canada. The tank design is like the 1974 CB125 model . 2004 CG125 Engine Engine Type Air-cooled 4-stroke OHV single cylinder Displacement 124cc Bore and Stroke 56.5 x 49.5mm Compression Ratio 9.5:1 …

1981 GL500I’81 Silver Wing Interstate Colors: Candy Muse Red Cosmo Black Metallic The pinstripes were gold The bike had a Pro-Link suspension and a dual front disc brake The modular seat and trunk design had three configurations: A dual seat with no trunk; a solo seat with a small trunk, a solo seat with a …

1974 Elsinore CR125M0 ENGINE Engine Type: Single cylinder 2-stroke port Ignition: CDI (capacitor discharge ignition) DRIVETRAIN Transmission: 6-speed CHASSIS / SUSPENSION / BRAKES N/A DIMENSION N/A OTHER Only one color was available: Custom Silver Metallic with Expert Green The number plate panels and the top of the fuel tank were green, but the fenders were …
