1968-69 CL175K0 Scrambler Engine Engine Type 174cc OHC parallel twin cylinders Displacement 174cc Cylinders inclined from vertical DRIVETRAIN Transmission 5-speed CHASSIS / SUSPENSION / BRAKES Frame Tubular backbone frame DIMENSION N/A OTHER Color Metallic Silver Candy Orange Candy Blue The gas tank and side covers were the basic color The upper forks, fork boots, and …

2013 Honda NCH50 Metropolitan   Engine Engine Type 49cc single-cylinder four-stroke Fuel Delivery PGM-FI with automatic enrichment Ignition CDI DRIVETRAIN Transmission Automatic V-Matic belt drive CHASSIS / SUSPENSION / BRAKES N/A Front Suspension Twin-downtube fork; 2.1 inches travel Rear Suspension Single shock; 2.3 inches travel Front Brakes Drum Rear Brake Drum with CBS Front Tire …

2010 Honda VT750C2B Phantom Engine Engine Type Liquid-cooled 52-degree V-tw Displacement 745 cc Bore And Stroke 79 mm x 76 mm Compression Ratio 9.6:1 Valve Train Chain-driven SOHC, 3 valves per cylinder Fuel Delivery PGM-FI with automatic enrichment circuit, one 34mm throttle body Ignition Digital transistorized with electronic advance DRIVETRAIN Transmission Wide-ratio five-speed Final Drive …

1979 Honda GL400 Custom Engine Engine Type Liquid cooled, four stroke, longitudinal 800 V-twin cylinder, SOHC 4 valves per cylinder operated by pushrods Displacement 396cc Bore and Stroke 73 mm x 47.4 mm Compression Ratio 10.0:1 Valves 2 valves/cylinder Max Power 40 hp @ 9500 rpm Max Torque 3.22 kg-m @ 7500 rpm Drivetrain Transmission …

1970 Honda Motosport SL175K0 Engine Engine Type OHC parallel twin cylinders Displacement 174cc Exhaust 2-into-1 DRIVETRAIN Transmission 5-speed Clutch manual (non-hydraulic) CHASSIS / SUSPENSION / BRAKES N/A DIMENSION N/A OTHER Color Candy Topaz Orange Candy Ruby Red Candy Sapphire Blue The fuel tank had white stripes The “175” side cover decal was white The muffler …

1974 CB550K0 550 Four Engine Engine Type Air cooled, transverse four cylinder, four stroke, SOHC, wet sump Bore and Stroke 58.5 x 50.6 mm Valves 2 valves per cylinder Displacement 544 (33.2 cid) Compression Ratio 9.0:1 Fuel Delivery Four 22mm Keihin carburetors Ignition Breaker points and condenser Max Power 50 hp @ 8500 rpm Max. …

1975 Trials TL250K0 ENGINE Engine Type: 4-stroke OHC 4-valve single cylinder Displacement: 248cc DRIVETRAIN Transmission: 5-speed CHASSIS / SUSPENSION / BRAKES N/A DIMENSION N/A OTHER One color was available: Special Silver Metallic with Tahitian Red The fuel tank was 2-tone red and silver The “TL250” side cover decal was orange and red The serial number …

1980 CB400T’80 Hawk It came in two Colors: Custom Silver Metallic or Black The pinstripes on the silver bike were red and black; but on the black bike they were orange and yellow The wheels were solid black comstar The brake caliper had a single piston The front fender was chrome plated steel The engine …

1969 CB175K3 Early model Super Sport 175 Engine Engine Type OHC parallel twin cylinders Displacement 174cc DRIVETRAIN Transmission 5-speed CHASSIS / SUSPENSION / BRAKES N/A DIMENSION N/A OTHER Color Candy Blue with white Candy Orange with white The gas tank was a two-tone with a black rubber pad The “HONDA” tank emblem was in the …

2010 Honda VT750RS Shadow RS Engine Engine Type liquid-cooled 52° V-twin Displacement 745cc Bore and Stroke 79mm x 76mm Compression Ratio 9.6:1 Fuel Delivery 133 bhp at 10,000 rpmProgrammed Fuel Injection (PGM-FI) incorporates a single 34mm-diameter throttle body for improved fuel efficiency, easy startups and lower emissions DRIVETRAIN Transmission Wide-ratio fi ve-speed Final Drive O-ring-sealed …

2002 Metropolitan (CHF 50) Engine Engine 49cc liquid-cooled single-cylinder four-stroke Bore & Stroke 38mm x 44mm Compression ratio 12: 1 Valve Train SOHC Fuel Delivery 15mm CV with automatic choke DRIVETRAIN Transmission Automatic Final Drive Belt drive CHASSIS / SUSPENSION / BRAKES Front Suspension Twin-downtube fork; 48mm travel Rear Suspension Single shock; 66mm travel Front …

1983 Nighthawk 550 (CB550SC’83) Engine Engine Type Air cooled, transverse four cylinder, four stroke, DOHC Bore and Stroke 60 x 50.6 mm Valves 4 valves per cylinder. Displacement 572 (34.9 cid) Compression Ratio 9.5:1 Fuel Delivery Four 26.8mm Keihin CV Ignition Transistorized pointless Starter Electric Fuel type Regular gasoline Alternator Brushless Max Power 64 hp …

2007 SH300I Engine Engine Type Liquid-cooled 4-stroke 4-valve SOHC single Displacement 279.1cm3 Bore and Stroke 72 x 68.5mm Compression Ratio 10.5:1 Carburation PGM-FI electronic fuel injection Max. Power Output 20kW/8,250min-1 (95/1/EC) Max. Torque 26Nm/6,000min-1 (95/1/EC) Ignition Digital transistorised with electronic advance Starter Electric DRIVETRAIN Transmission V-Matic Final drive V-belt Wheels Front U-section 6-spoke cast aluminium,16 …

2012 Honda Crossrunner 800 Engine Engine Type Liquid-cooled 4-stroke 16-valve DOHC 90° V-4 Displacement 782cc Bore and Stroke 72 X 48mm Compression Ratio 11.6:1 Spark Plug Type IMR9D-9H (NGK); VNH27Z (DENSO) Fuel Delivery PGM-FI electronic fuel injection Throttle Bore 36mm Idling Speed 1200min-1 Ignition System Computer-controlled digital transistorised with electronic advance Ignition Timing 8° BTDC …

2001 VT750DC’01 SHADOW SPIRIT 750 Engine Engine Type 745cc Liquid cooled, 52° V-twin, single pin crank Bore And Stroke 79mm x 76mm Compression Ratio 9:1 Carburetion Twin 36mm, diaphragm-type CV Valve Train SOHC; three valves per cylinder Ignition Starting DRIVETRAIN Transmission Wide-Ratio, 5-speed Final Drive “O” ring chain CHASSIS / SUSPENSION / BRAKES Front Suspension …

1959-60 Dream Touring 300 C76 Colors: White Black Blue Scarlet Red The handlebars were low-rise, pressed steel and painted The fuel tank is one of the four basic colors with a solid chrome plate, but no rubber knee pad It had a square headlight with an integrated speedometer The engine was a 305cc 4-stroke OHC …

1961-68 Honda Super Hawk 305 (CB77) Engine Engine Type Air cooled, four stroke, parallel twin cylinder SOHC Displacement 305cc Bore and Stroke 60 x 54 mm Compression Ratio 9.5:1 Carburetors Twin Starter Kickstart Max Power 16.8 KW (23.8 hp) @ 7500 rpm Max Torque 23.1 NM @ 6000 rpm DRIVETRAIN Transmission 4-speed Clutch Wet multi-plate …

1989 PC800 It was available in one color scheme: Pearl Pacific White with Ocean Gray Metallic It featured an underseat storage compartment The engine was a 800cc SOHC 3-valve liquid-cooled V-twin linked to a 5-speed transmission and shaft drive The serial number began JH2RC340*KM000015. 1990 PC800 It was available in one color scheme: Candy Glory …

1996 XR400 (XR400R’96) It was a development of the motosport series in previous years It was sold in 1996 One color was available: Ross White This was an all new lightweight, midweight XR The rear sub frame was removable The swingarm pivot was combined with the rear engine mount A high performance power kit was …

1988 VT800’88 Shadow 800 It came in one of two color schemes: Black with Candy Glory Red or Candy Wineberry Red with Dry Silver Metallic The gas tank was 2-tone The side covers were chrome The “SHADOW” tank decal was silver on the black bike; but it was gold on the red one The engine …

1965-68 Scrambler 305 (CL77) Colors: Blue Red Black The fuel tank, side covers, and fenders were silver The frame, upper fork, and headlight shell were painted one of the basic colors The fuel tank had a rubber knee pad The two exhaust pipes were mounted on the left side and converged into a single muffler …

1981 CB900F’81 900 Super Sport ENGINE Engine type: 902cc DOHC 4-valve inline 4 cylinder Exhaust system: Four-into-two DRIVETRAIN Transmission: 5-speed Final drive: Chain CHASSIS / SUSPENSION / BRAKES N/A DIMENSION N/A OTHER Colors: Black Pleiades Silver Metallic The stripes on the black bike were orange and red; but on the silver bike they were dark …

2000 CB600F Hornet Engine Type Liquid-cooled 4-stroke, Bore and Stroke 65 x 45.2mm Displacement  599cc Compression Ratio 12:1 Carburation Four 34mm downdraft flat-slide CV-type Max. Power Output [email protected],750rpm Max. Torque 45lb/[email protected],250rpm Ignition Computer-controlled digital transistorized with electronic advance Starter Electric Gearbox 6-speed Final Drive ‘O’-ring sealed chain Dimensions 2095 x 740 x 1065mm Wheelbase 1425mm …

1972-73 CB350F0 Four Engine Engine Type Air cooled, transverse four cylinder, four stroke, SOHC, 2 valve per cylinder. Displacement 347cc Bore and Stroke 47 x 50. mm Compression Ratio 9.3:1 Ignition Breaker points and condenser Starter Electric and kickstart Max Power 34 hp @ 9500 rpm Max Torque 2.79 m-kg @ 8000 rpm Fuel Delivery …

1982 VF400F Engine Engine Type 399 cc, 4 Stroke – Liquid Cooled – V Four Bore and Stroke 55 mm x 42 mm Compression Ratio 11:1 Valves DOHC, 4 valves/cylinder Fuel Delivery VD40 Ignition Full transistor Horsepower 55.5 hp (41.9 kW) @ 12500 rpm Maximum Torque 35.5 Nm (26.8 ft. lbs) @ 10500 rpm Starting …

1993 CBR900RR It was available in one of two color schemes: Ross White with Real Blue and NR Red or Black with Seed Silver Metallic and NR Red Within the fairing were twin round headlights The fairing featured “perforation technology.” The bike weighed 408 lb (105 kg.) (dry) The engine was a 893cc DOHC liquid-cooled …

2004 Shadow Aero 750 Engine Engine Type 745cc liquid-cooled 52-degree V-twin Bore And Stroke 79mm x 76mm Compression Ratio 9.6: 1 Fuel System Single 34.0mm CV type Valve Train SOHC; three valves per cylinder Ignition CD with electronic advance, two spark plugs per cylinder Starting DRIVETRAIN Transmission Wide-Ratio, 5-speed Final Drive Shaft CHASSIS / SUSPENSION …

1969-70 Motosport 350 (SL350K0) Colors: Candy Sapphire Blue Candy Ruby Red Candy Gold The fuel tank stripe was white The frame had a single downtube It had both a electric and kick starter The engine was a 325cc 4-stroke OHC parallel twin with two CV carburetors The transmission was a 5-speed The front wheel was …

1982 CM450A-82 Hondamatic Colors: Candy Muse Red with Candy Antares Red Candy Empire Blue with Candy Dark Blue The gas tank and side covers were two-tone The “CM450A HONDAMATIC” side cover decal was gold The comstar wheels were highlighted black The speedometer had a 85 mph (135 kph) limit The engine was a 447cc SOHC …

1993 CBR900RR ENGINE N/A DRIVETRAIN N/A CHASSIS / SUSPENSION / BRAKES N/A DIMENSION N/A OTHER It was available in one of two color schemes: Ross White with Real Blue and NR Red or Black with Seed Silver Metallic and NR Red Within the fairing were twin round headlights The fairing featured “perforation technology.” The bike …

2004 CBF600 Engine Engine Type Inline 4 Cyliner, Liquid-cooled 4-stroke 16-valve DOHC Bore and Stroke 65 x 45.2mm Displacement 600cc Compression Ratio 11.6 :1 Fuel Delivery 34mm slanted flat-slide VP- type carburetors x 4 Max. Power Output 76 bhp at 10,500 rpm Max. Torque 58Nm at 8000 rpm Ignition Computer-controlled digital system Starter Electric DRIVETRAIN …

1968-69 CL350K0 Colors: Daytona Orange with White Candy Red with White Candy Blue with White The gas tank was a two-tone The upper forks were black in the early model and the basic color (orange, red, or blue) in later models The side covers and headlight shell were white The seat was not pleated The …

1992 Honda CB450DX Engine Engine Type Air cooled, parallel twin cylinder, four stroke, SOHC, 3 valves per cylinder Displacement 447cc (27 cu. in.) Bore and Stroke 75 X 50.6 mm Compression Ratio 9.1:1 Fuel Delivery Two 30mm Keihin CV Ignition CDI Starter Electric Max Power 43.3 hp @ 8500 rpm Max Torque 4.3Kgm 42.1Nm @ …

1987 Honda CB450S Engine Engine Type Air cooled, parallel twin cylinder, four stroke, SOHC, 3 valves per cylinder, 360� crankshaft and twin balance-shafts Displacement 447cc (27 cid) Bore and Stroke 75 X 50.6mm Compression Ratio 9.1:1 Fuel Delivery Two 30mm Keihin CV Ignition CDI Starter Electric Max Power 45 hp 32.8 KW @ 9000 rpm …

2000 Honda CBR929RR Engine Engine Type 929 cc, water cooled, 4 – cylinders in line, 4-stroke Bore And Stroke 74 mm x 54 mm Compression Ratio 11.3: 1 Fuel System PGM-FI (fuel-injection) with automatic choke Valve DOHC, 4 valves per cylinder Ignition Computer-controlled digital with three-dimensional mapping Power 152 hp (113.3 kW) @ 11000 rpm …

2001 VT750DC’01 SHADOW SPIRIT 750 Engine Engine Type 745cc Liquid cooled, 52° V-twin, single pin crank Bore And Stroke 79mm x 76mm Compression Ratio 9:1 Fuel System Twin 36mm, diaphragm-type CV Valve Train SOHC, 3 valve per cylinder Ignition Starting DRIVETRAIN Transmission Wide-Ratio, 5-speed Final Drive “O” ring chain CHASSIS / SUSPENSION / BRAKES Front …

1968-69 CA175 Touring 175 (CD175) Engine Engine Type OHC parallel twin cylinders Displacement 174cc Fuel delivery Single carburetor Cylinders inclined forward from vertical DRIVETRAIN Transmission 4-speed Final drive Fully enclosed chain CHASSIS / SUSPENSION / BRAKES Frame Pressed steel of the backbone type DIMENSION N/A OTHER Color Black Candy Red Candy Blue The tank emblem …

1980 CB900C’80 900 Custom It was available in one of two color: Candy Muse Red or Candy Poseidon Blue The pinstripes were gold and red The exhaust was a 4-into-4 The transmission was a 5-speed with a dual range sub-transmission thus giving it 10 actual speeds The engine was a 902cc DOHC 4-valve inline 4 …

1973 XL175K0 Engine Engine Type OHC single cylinder Displacement 173cc DRIVETRAIN Transmission 5-speed CHASSIS / SUSPENSION / BRAKES N/A DIMENSION N/A OTHER Color Mars Orange with Silver The gas tank and side covers were orange The stripe was black The fenders were silver painted plastic The “XL175” side cover decal was white The instruments contained …

1982 CB450T’82 Engine Engine Type Air cooled, parallel twin cylinder, four stroke, SOHC, 3 valves per cylinder, 360� crankshaft and twin balance-shafts Displacement 447cc (27 cid) Bore and Stroke 75 X 50.6mm Compression Ratio 9.1:1 Fuel Delivery Two 30mm Keihin CV Ignition CDI Starter Electric Max Power 45 hp 32.8 KW @ 9000 rpm Drivetrain …
