Honda Dylan 125 Motorcycles
2004 Dylan 125 Engine Engine Type Liquid-cooled 4-stroke SOHC single Displacement 125cc Bore and Stroke 52.4 x 57.8mm Compression Ratio 11.0 :1 Fuel Delivery 26mm VK-type Ignition Digital transistorised with electronic advance Max. Power Output 14bhp at 9000 rpm Max. Torque 11.3Nm at 7250 rpm Starter Electric DRIVETRAIN Transmission V-Matic Final Drive V-belt Front Wheel …
Honda CB500 Four Police Motorcycles
500 Four Police (CB500P) The fuel tank panel was white The exhaust was a 4-into-4 system The engine was a 498cc SOHC inline 4-cylinder with 4 carburetors The transmission was a 5-speed.
Honda Gold Wing GL1500 Motorcycles
1988 GL1500’88 1988 was one of the most significant years for Honda with the introduction of a six-cylinder powerplant In many ways it was the natural evolution of the Gold Wing; however the progression to this model made it significantly different While all the previous Wings had been made in the United States, some, this …
Honda Gold Wing 1100 (GL1100) Motorcycles
1980 GL1100’80 Engine Engine Type Liquid-cooled four cylinder horizontally opposed O Engine Displacement 1085 cc Bore and Stroke 75 x 61.4 mm Compression Ratio 9.2:1 Valve Train 2 valves/cylinder Fuel Delivery four 30 mm, CV type Exhaust system Four-into-two with balance tube Ignition Transistorized pointless Fuel type regular gasoline Horsepower 81 hp (60.4 kW) @ …
Honda Shadow VT500C Motorcycles
1983 Shadow 500 (VT500C’83) Colors: Candy Wineberry Red Black The fuel tank and rear fender were one of the two basic colors (red or black), but the side covers were chrome and the engine covers were black The side cover decal “Shadow 500” was black and red with gold overlay The headlight was rectangular and …
Honda XL100 Motorcycles
1974 XL100K0 Engine Engine Type OHC single cylinder Displacement 99cc DRIVETRAIN Transmission 5-speed CHASSIS / SUSPENSION / BRAKES N/A DIMENSION N/A OTHER Color: just one color: Candy Topaz Orange The “HONDA” decal on the tank and the “XL100” decal on the side cover were both black The shock springs were chrome The seat was pleated …
Honda CR80RB “Expert” Motorcycles
1996 CR80RB’96 Engine Engine Type 83cc 2-stroke reed valve, liquid-cooled single cylinder Cylinder Nikasil® Spark plug BR10EG Plug gap .024 DRIVETRAIN Transmission 6-speed Front wheel 19″ Rear wheel 16″ wheel The wheel rims were aluminum alloy The rear tire is a Dunlop K695 CHASSIS / SUSPENSION / BRAKES N/A DIMENSION N/A OTHER called the “Expert” …
Honda GL18B Motorcycles
2007 GL18b Gold Wing Airbag Overview: With its unrivaled combination of power, luxury and sporting capability, the 1832cc Gold Wing continually redefines the touring class. New for 2007, the airbag-equipped model is the greatest revolution in motorcycle technology since the introduction of the Gold Wing itself. It’s in a class of its own. Engine Type1832cc …
Honda Silver Wing GL500 Motorcycles
1981 Silver Wing (GL500’81) Colors: Candy Muse Red Cosmo Black Metallic It had gold pinstripes, pro-link suspension, and a single front disc brake Three configurations of seat and trunk design were available: dual seat with no trunk, solo seat with a small trunk, solo seat with backrest and a large trunk The engine was a …
Honda Elite 125, CH125, Scooter, Motorcycles
1983 Elite Engine Engine Type Liquid-cooled four-stroke 124cc DRIVETRAIN Transmission V-maticTM Drive Belt CHASSIS / SUSPENSION / BRAKES N/A DIMENSION Dry weight 102 kg (224.8 lb) Seat Height 760mm (29.9 in.) Wheelbase 1200mm (47.2 in.) OTHER Seat Dual Accessory Rear carrier 1984 Elite Engine Engine Type Liquid-cooled four-stroke 124cc Displacement 124cc Bore and Stroke …
Honda Elite 150 (CH150D) scooter
1985 Elite 150 Deluxe (CH150D) Engine Engine Type Liquid-cooled, SOHC, Four-stroke Displacement 152.7cc Bore & Stroke 58 x 57.8mm Compression Ratio 10:1 Fuel Delivery 22mm, CV type Ignition CDI Starting system Electric DRIVETRAIN Transmission Variable Ratio, V-MaticTM Clutch Centrifugal, Automatic Drive line Belt Wheels Pressed steel CHASSIS / SUSPENSION / BRAKES Front Suspension Trailing-link type …
Honda Super Sport CB100 Motorcycles
1970 Super Sport 100 (CB100K0) Engine Engine Type 99 cc, air cooled, single cylinder, 4-stroke Bore and Stroke 50.5 mm x 49.5 mm Valves 2 valves/cylinder Horsepower 11.5 hp (85.8 kW) @ 11000 rpm Battery 6N6-3B — 6 volt DRIVETRAIN Transmission 5 speed Final Drive Chain CHASSIS / SUSPENSION / BRAKES Front Tire 2.50-18 Rear …
Honda CB500 Twin Super Sport Motorcycles
1974-75 500 Twin DOHC (CB500T0) Engine Engine Type Air cooled, parallel twin cylinder, four stroke, DOHC, 2 valves per cylinder, Bore and Stroke 70.0 x 64.8 mm Ignition Breaker points and condenser Displacement 499cc (30.4 cid) Compression Ratio 8.5:1 Fuel Delivery Dual CV Keihin Carburetors Max. Power Output 42 hp 30.7 KW @ 8000 rpm …
Honda GL18HPN Motorcycles
2007 GL18HPN Gold Wing Audio/Comfort/Navi Overview: With its unrivaled combination of power, luxury and sporting capability, the 1832cc Gold Wing continually redefines what a touring motorcycle can be. The Gold Wing Premium Audio, Comfort Package & Navi features a fully integrated, flash-card based Honda Satellite-Linked NavigationTM System. Available only on the Gold Wing. It’s in …
Honda Tourist Trophy GB500 Motorcycles
1989 Tourist Trophy (GB500’89) It was designated GB500L’89 in California One color was available: Black Green Mettalic with gold pinstriping and emblems It had both electric start and a kick starter The engine was a 499cc 4-stroke OHC RFVC dry sump single cylinder with a 5-speed transmission The California serial number began JH2PC161*KK000003 while the …
Honda Elite 150 (CH150) scooter
1985 Elite 150 (CH150) Engine Engine Type Liquid-cooled, SOHC, Four-stroke Displacement 152.7cc Bore & Stroke 58 x 57.8mm Compression Ratio 10:1 Fuel Delivery 22mm, CV type Ignition CDI Starting system Electric DRIVETRAIN Transmission Variable Ratio, V-MaticTM Clutch Centrifugal, Automatic Drive line Belt Wheels Pressed steel CHASSIS / SUSPENSION / BRAKES Front Suspension Trailing-link type Rear …
Honda Innova ANF125 Motorcycles
2004 ANF125 Innova Engine Engine Type Air-cooled 4-stroke SOHC single Displacement 124.9cc Bore and Stroke 52.4 x 57.9mm Compression Ratio 9.3 :1 Fuel Delivery 18mm APB-type carburetor Ignition Capacitor Discharge (CDI) with electronic advance Max. Power Output 9 bhp at 7500 rpm Max. Torque 10Nm at 5000 rpm Starter Electric and Neutral kick DRIVETRAIN Transmission …
Honda XL80S Motorcycles
1980 XL80S-80 Engine Engine Type 80cc OHC single cylinder Spark plug C7HSA Plug gap .028 Battery 6N4C-1B — 6 volt DRIVETRAIN Transmission 4-speed transmission with manual clutch. Chain #420 x 96 Front sprocket 15 T Rear sprocket 37 T CHASSIS / SUSPENSION / BRAKES N/A DIMENSION N/A OTHER The Honda XL80S-80 was sold in 1980 …
Honda Motosport XR500 Motorcycles
1979 XR500’79 It came in Tahitian Red The “HONDA” tank decal was red The top of the tank, side cover panels, and headlight cowl were black The “XR500” side cover graphic was red and white The front wheel was 23″ while the rear was 18″ The engine was a 498cc OHC 4-valve single cylinder with …
Honda Elsinore MT125 Motorcycles
1974 MT125K0 Elsinore ENGINE N/A DRIVETRAIN N/A CHASSIS / SUSPENSION / BRAKES N/A DIMENSION N/A OTHER Color: one color combination: custom Silver Metallic and Blue The gas tank was silver with a blue stripe on top The fenders were silver painted plastic The side cover was metallic silver The exhaust system heat shield was chrome …
Honda CB550F Super Sport Motorcycles
1975 CB550F0 Super Sport 550 Four Engine Engine Type Air cooled, transverse four cylinder, four stroke, SOHC, 2 valves per cylinder. Bore and Stroke 58.5 x 50.6 mm Ignition reaker points and condenser Displacement 544cc (33.2 cid) Compression Ratio 9.0:1 Fuel Delivery Four Keihin, 22 mm diameter carburetors Max. Power Output 50 hp @ 8500 …
Honda GL18P Motorcycles
2007 GL18P Gold Wing Premium Audio Overview: With its unrivaled combination of power, luxury and sporting capability, the 1832cc Gold Wing continually redefines what a touring motorcycle can be. The Gold Wing Premium Audio model features six speaker elements and an 80-watts-per-channel external amplifier. You can even add an optional six-disc CD player. It’s in …
Honda PCX150 Motorcycles
2011 Honda PCX150 Engine Engine Type 125cc liquid-cooled single-cylinder four-stroke Bore and Stroke 52.4mm x 57.9mm Compression Ratio 11.0:1 Valve Train SOHC; two-valve Fuel Delivery PGM-FI with automatic enrichment Ignition Digital with electronic advance DRIVETRAIN Transmission Honda V-Matic belt-converter automatic transmission CHASSIS / SUSPENSION / BRAKES Front Suspension 31mm hydraulic fork; 3.5 inches of travel …
Honda NX125 Motorcycles
1988 NX125 ENGINE N/A DRIVETRAIN N/A CHASSIS / SUSPENSION / BRAKES N/A DIMENSION N/A OTHER It was also called the NX125L’88 in a special California only market As the designation implies, it was sold in 1988 Only one color was available: Ross White The seat and fork boots were blue, while the frame was silver …
Honda Magna 1100 (VF1100C) V65 Motorcycles
1983 VF1100C’83 V65 Magna Engine Engine Type 65 cu. in., liquid-cooled, 1098cc, 90° V-4, DOHC Bore and Stroke 79.5 mm x 55.3 mm Valves 4 valves/cylinder Horsepower 100 hp (74.6 kW) @ 9500 rpm Maximum Torque 94 Nm (69.3 ft. lbs) @ 7500 rpm Drivetrain Transmission Five-speed plus overdrive sixth Shaft Shaft CHASSIS / SUSPENSION …
Honda CRF100F Motorcycles
2004 CRF100F Engine Engine Type 99cc air-cooled single-cylinder four-stroke Compression Ratio 8.4:1 Bore and Stroke 53.0mm x 45.0mm Valve Train OHC; two-valve Fuel Delivery 22.0mm piston-valve Ignition CDI DRIVETRAIN Transmission Five-speed Final Drive #428 chain; 14T/50T CHASSIS / SUSPENSION / BRAKES Front Suspension 27.0mm leading-axle Showa fork; 5.2-inch travel Rear Suspension Pro-Link Showa single shock; …
Honda Pantheon FES125 Motorcycles
2004 FES125 Pantheon Engine Engine Type Liquid-cooled 4-stroke SOHC single Displacement 124.6cc Bore and Stroke 52.4 x 57.8mm Compression Ratio 11:1 Carburation PGM-FI electronic fuel injection Ignition Digital transistorised with electronic advanced Max. Power Output 13.5 bhp at 9000 rpm Max. Torque 11.7Nm at 8500 rpm Starter Electric DRIVETRAIN Transmission Automatic centrifugal Final Drive Belt …
Honda SH150i Motorcycles
2010 SH150i Engine Engine Type 153cc liquid-cooled single-cylinder four-stroke Bore and Stroke 58mm x 57.8mm Compression Ratio 11.0:1 Valve Train SOHC; two-valve Fuel Delivery Programmed Fuel Injection (PGM-FI) with automatic enricher circuit Ignition Digital transistorized with electronic advance DRIVETRAIN Transmission Honda V-Matic belt-converter automatic transmission CHASSIS / SUSPENSION / BRAKES Front Suspension 33mm hydraulic …
Honda NRX1800 Motorcycles
2004 Valkyrie Rune 1800 NRX1800 Engine Engine Type 1832cc liquid-cooled horizontally opposed six-cylinder Bore and Stroke 101mm x 112mm Compression Ratio 9.8: 1 Valve Train SOHC; two valves per cylinder Ignition Digital with three-dimensional mapping, two spark plugs per cylinder Transmission Five-speed Final Drive Shaft Front Suspension Trailing bottom link; 3.9-inch travel Rear Suspension …
Honda PCX125 Motorcycles
2012 Honda PCX125 Engine Engine Type 4-stroke 2-valve SOHC with built-in liquid cooling Displacement 124.9cc Bore and Stroke 52.4 x 57.9mm Compression Ratio 11:1 Fuel Delivery PGM-FI electronic fuel injection Carburation PGM-FI electronic fuel injection Ignition Fully transistorised electric Max. Power Output 8.33kW/8,000min-1 (95/1/EC) Max. Torque 11.56Nm/6,000min-1 (95/1/EC) Starter Electric DRIVETRAIN Transmission V-Matic – Centrifugal …
Honda 750 Super Sport (CB750F) Motorcycles
1975 CB750F0 750 Super Sport It was available in one of two colors: Flake Sunrise Orange or Candy Sapphire Blue The exhaust was a 4-into-1 The tank and rear cowl wer the basic color (orange or blue); but the side covers were black The wheels were wire spoked with a single front disc brake and …
Honda Sabre VF1100 V65 Shadow Sabre, VF1100S
1983 VF1100S’83 V65 Sabre Engine Engine Type 1098 cc, 4 Stroke – Liquid Cooled – V-Four Bore and Stroke 79.5 mm x 55.3 mm Valves 4 valves/cylinder Horsepower 121 hp (90.2 kW) @ 9500 rpm Maximum Torque 94 Nm (69.3 ft. lbs) @ 7500 rpm Drivetrain Transmission 6-speed Final Drive Shaft CHASSIS / SUSPENSION …
Honda Trail Bike (CT90) Motorcycles
1966-68 Trail 90 CT90K0 Engine The engine was improved to a 89cc OHC single cylinder Spark plug D8HA Plug gap .028 DRIVETRAIN Clutch automatic Chain #428 x 104 The early 4-speed model had a dual overlay rear sprocket setup The later models had a single sprocket but an 8-speed dual range transmission Front sprocket 15 …
Honda CR85R Motorcycles
2003 Honda CR85R Engine Engine Type 84.7cc liquid-cooled single-cylinder two-stroke Spark plug BR10EG Plug gap .024 Bore and Stroke 47.5 x 47.8 mm Compression Ratio 8.4:1 Fuel Delivery 28mm piston-valve DRIVETRAIN Transmission Close-ratio six-speed Final Drive #420 chain; 15T/50T CHASSIS / SUSPENSION / BRAKES Front Suspension 37mm inverted Showa fork with fully adjustale compression and …
Honda Unicorn Motorcycles
2005 Unicorn OVERVIEW Available in India, two versions were offered: Kickstart or Selfstart Engine Engine Type Four stroke, Air Cooled, OHC Single Cylinder Displacement 149.1cc Net Power 13.3 bhp @ 8000 rpm (9.9 kW) Torque 1.3 Kg-m @ 5500 rpm (12.8 Nm) Air Filter Paper Type ACG Power Generating Capacity 125 watt Oil Capacity …
Honda PS125i Motorcycles
2007 PS125i Engine Engine Type Liquid-cooled 4-stroke SOHC single Displacement 125cc Bore and Stroke 52.4 x 57.8mm Compression Ratio 11:1 Carburation PGM-FI electronic fuel injection Ignition Digital transistorised with electronic advanced Max. Power Output N/A Max. Torque N/A Starter Electric DRIVETRAIN Transmission V-Matic Final Drive Belt drive Front Wheel 13 M/C x MT2.75 U-section 6-spoke …
Honda Scrambler CL160, CL160D Motorcycles
1966-67 CL160 Scrambler Engine Engine Type OHC parallel twin cylinders Displacement 161cc Fuel delivery dual carburetors Starter kick start only DRIVETRAIN Transmission 4-speed CHASSIS / SUSPENSION / BRAKES N/A DIMENSION N/A OTHER Color Dark Silver with Black The tank, side covers, fenders, and fork legs were silver The seat, frame, upper forks, and headlight case …
Honda Super Sport CB160 Motorcycles
1968-69 CB160 Sport 160 Engine Engine Type OHC parallel twin cylinders Displacement 161cc Displacement Duel carburetors DRIVETRAIN Transmission 4-speed CHASSIS / SUSPENSION / BRAKES N/A DIMENSION N/A OTHER Color Black with Silver Scarlet Red with Silver Blue with Silver White with Silver The gas tank, frame, forks, and rear shocks were the basic color (black, …
Honda Shadow 1100 (VT1100) Motorcycles
1985 VT1100C’85 Shadow 1100 Colors: Black with Red Black with Silver The gas tank was two-tone black with red or silver; but the side cover was two-tone black with silver The “SHADOW” side cover decal was silver The engine was a 1099cc SOHC 3-valve liquid-cooled V-twin linked to a 5-speed transmission and shaft drive The …
Honda CR85RB Expert Motorcycles
2004 CR85R Expert Engine Engine Type 84.7cc liquid-cooled single-cylinder two-stroke Spark plug BR10EG Bore and Stroke 47.5mm x 47.8mm Compression Ratio 8.4:1 Fuel Delivery Reed-valve Ignition CD with electronic advance DRIVETRAIN Transmission Honda V-Matic belt-converter automatic transmission Final Drive #420 chain x 126; 15T/56T CHASSIS / SUSPENSION / BRAKES Front Suspension 7mm fully adjustable leading-axle …
