2002 VTX1800S
Engine
|
|
| Engine |
1795cc liquid-cooled 52-degree V-twin |
| Bore and Stroke |
101.0mm x 112.0mm |
| Compression Ratio |
9.0: 1 |
| Valve Train |
SOHC; three valves per cylinder |
| Fuel Delivery |
PGM-FI with automatic enricher circuit |
Drivetrain
|
|
| Transmission |
Five-speed |
| Final Drive |
Shaft |
CHASSIS / SUSPENSION / BRAKES
|
|
| Front Suspension |
45mm inverted fork; 130mm travel |
| Rear Suspension |
Dual shocks with five-position spring preload adjustability; 100 millimetres travel |
| Front Brakes |
Dual 296mm disc with three-piston calipers |
| Rear Brakes |
Single 316mm disc with twin-piston caliper |
| Front Tires |
150/80-17 |
| Rear Tires |
170/80-15 |
DIMENSION
|
|
| Wheelbase |
1715mm (67.5 inches) |
| Seat Height |
698mm (27.5 inches) |
| Dry Weight |
336 kg. (741 lb.) |
| Fuel Capacity |
20 litres (4.4 gallons) |
OTHER
|
|
| Colors |
|
2003 VTX1800S
Engine
|
|
| Engine |
1795cc liquid-cooled 52-degree V-twin |
| Bore and Stroke |
101.0mm x 112.0mm |
| Compression Ratio |
9.0: 1 |
| Valve Train |
SOHC; three valves per cylinder |
| Fuel Delivery |
PGM-FI with automatic enricher circuit |
Drivetrain
|
|
| Transmission |
Five-speed |
| Final Drive |
Shaft |
CHASSIS / SUSPENSION / BRAKES
|
|
| Front Suspension |
45mm inverted fork; 130mm travel |
| Rear Suspension |
Dual shocks with five-position spring preload adjustability; 100 millimetres travel |
| Front Brakes |
Dual 296mm disc with three-piston calipers |
| Rear Brakes |
Single 316mm disc with twin-piston caliper |
| Front Tires |
150/80-17 |
| Rear Tires |
170/80-15 |
DIMENSION
|
|
| Wheelbase |
1715mm (67.5 inches) |
| Seat Height |
698mm (27.5 inches) |
| Dry Weight |
336 kg. (741 lb.) |
| Fuel Capacity |
20 litres (4.4 gallons) |
OTHER
|
|
| Colors |
|
2005 VTX1800S
Engine
|
|
| Engine Type |
1795cc liquid-cooled 52-degree V-twin |
| Bore and Stroke |
101.0mm x 112.0mm |
| Compression Ratio |
9.0: 1 |
| Valve Train |
SOHC; three valves per cylinder |
| Fuel Delivery |
PGM-FI with automatic enricher circuit |
| Ignition |
Digital, two spark plugs per cylinder |
Drivetrain
|
|
| Transmission |
Five-speed |
| Final Drive |
Shaft |
CHASSIS / SUSPENSION / BRAKES
|
|
| Front Suspension |
45mm inverted fork; 130mm travel |
| Rear Suspension |
Dual shocks with five-position spring preload adjustability; 100 millimetres travel |
| Front Brakes |
Dual 296mm disc with three-piston calipers |
| Rear Brakes |
Single 316mm disc with twin-piston caliper |
| Front Tires |
150/80R-17 radial |
| Rear Tires |
180/70R-16 radial |
DIMENSION
|
|
| Wheelbase |
67.5 inches |
| Rake |
32.0° |
| Trail |
163mm (6.4 inches) |
| Seat Height |
27.3 inches |
| Dry Weight |
750 lb |
| Fuel Capacity |
5.3 GalUS |
OTHER
|
|
| Colors |
-
- Black
- Black/Candy Black Cherry
- Black/Metallic Green
- California version differs slightly due to emissions equipment.
|
2006 VTX1800S
Engine
|
|
| Engine Type |
1795cc liquid-cooled 52-degree V-twin |
| Bore and Stroke |
101.0mm x 112.0mm |
| Compression Ratio |
9.0: 1 |
| Valve Train |
SOHC; three valves per cylinder |
| Fuel Delivery |
Programmed Fuel Injection (PGM-FI) with automatic choke |
| Ignition |
Digital, two spark plugs per cylinder |
Drivetrain
|
|
| Transmission |
Five-speed |
| Final Drive |
Shaft |
CHASSIS / SUSPENSION / BRAKES
|
|
| Front Suspension |
45mm inverted fork; 130mm travel |
| Rear Suspension |
Dual shocks with five-position spring preload adjustability; 100 millimetres travel |
| Front Brakes |
Dual 296mm disc with three-piston calipers |
| Rear Brakes |
Single 316mm disc with twin-piston caliper |
| Front Tires |
150/80R-17 radial |
| Rear Tires |
180/70R-16 radial |
DIMENSION
|
|
| Wheelbase |
67.5 inches |
| Rake |
32.0° |
| Trail |
163mm (6.4 inches) |
| Seat Height |
27.3 inches |
| Dry Weight |
750 lb |
| Fuel Capacity |
5.3 GalUS |
OTHER
|
|
| Emissions |
Meets current CARB and EPA standards. |
| Colors |
-
- Metallic Silver
- Candy Orange/Black
- Gold/Black
|
| Model ID |
VTX1800S1 |
