2020 Harley-Davidson Iron 1200 [Model Overview]

2020 Harley-Davidson Iron 1200

2020 Harley-Davidson Iron 1200

The 2020 Harley-Davidson Iron 1200 takes the Sportster to new heights with a retro-style and some higher handlebars. It’s a sportier motorcycle with Harley’s Evolution 1200 engine. With plenty of options and paint schemes to choose from, there’s likely an Iron 1200 for you.

The Iron 1200 gets a good looking V-twin engine with a displacement of 1,200cc. The V-twin is air-cooled and sounds like the classic Harley you expect. It’s Harley’s tried and true Evolution motor. The engine is mated to a five-speed manual transmission. The engine makes 60 hp and 73 lb-ft of torque.

The Iron 1200 offers a lot of what the Forty-Eight does but with a different kind of style and a lower price tag. It’s not the most powerful motorcycle out there, but it is unique. The bike has a starting price of $9,999.

The motorcycle is available in three colors: Vivid Black, Barracuda Silver, and Billiard Blue.

On this page: we’ve curated specs, features, news, photos/videos, etc. so you can read up on the new Harley-Davidson Iron 1200 in one place.

2020 Harley-Davidson Iron 1200

Model Overview

General Info

  • Price: $ 9,999
  • Key Features:
    • 1200cc Evolution® Engine
    • ABS
    • LED Lighting

Key Specs

  • Engine type: 1,200cc, Air-cooled, Evolution®
  • Engine Torque: 73 lb-ft
  • Wet weight: 547 lbs
  • Seat height: 25.7

2020 Harley-Davidson Iron 1200

2020 Harley-Davidson Iron 1200 Specifications

From Harley-Davidson


Engine 1,200cc, Air-cooled, Evolution®
Engine Torque 73 lb-ft
Bore x Stroke 3.5 in x 3.8 in.
Compression Ratio 10:1
Fuel System Electronic Sequential Port Fuel Injection (ESPFI)
Starter Electric


Transmission 5-speed
Final Drive Gear, 38/57 ratio


Suspension Front Black, 9-spoke
Suspension Rear Black, 9-spoke
Brakes Front Dual-piston front
Brakes Rear Dual-piston rear
Tires Front 100/90B19 57H
Tires Rear 150/80B16 77H
Fuel Tank Capacity 12.4 L (3.3 US gal.)
Color Vivid Black, Barracuda Silver, and Billiard Blue


Spark Plugs
Headlight LED
Tail Light LED


Overall Length 86.6 in (2,200 mm)
Overall Width
Overall Height
Wheelbase 59.6 in (1,515 mm)
Ground Clearance 4.3 in (110 mm)
Seat Height 25.7 in (652 mm)
Curb Weight 547 lbs (248 kg)



2020 Harley-Davidson Iron 1200

2020 Harley-Davidson Iron 1200 Features

1200cc Evolution® Engine

1200cc at your command to deliver tons of torque for an unforgettably fun ride.

Blacked-Out Finishes

Blacked-out finishes from its powertrain to its air cleaner cover to its exhaust. Equipped to take on the urban grid.

Throwback 70’s Custom Tank Art

Authentic bold 70’s-inspired tank graphic shows the bike’s retro roots.

Café Solo Seat

Sit “in” the bike while your hands and feet reach naturally to the controls. This seat pays homage to the heritage of the iconic Cafe Racer style.

Black Mini-Ape Handlebars

Fists in the wind attitude with a conservative rise and bend for rider comfort.

9-Spoke Cast Aluminum Wheels

Nine-spoke wheels that are black as night from rim to rubber to complement the Dark Custom look.


The fixed black speed screen leaves no question as to the attitude of the motorcycle. Get behind it and hang on.
