Honda CRF80F Motorcycles


2004 CRF80F

Engine

Engine Type 80cc air-cooled single-cylinder four-stroke
Bore and Stroke 47.5mm x 45.0mm
Compression Ratio 9.7:1
Spark plug CR7HSA
Plug gap .028
Valve Train SOHC; two-valve
Fuel Delivery 20.0mm piston-valve
Ignition CDI

DRIVETRAIN

Transmission Five-speed
Final Drive #420 chain x 110
Front sprocket 14T
Wheels Rear sprocket

CHASSIS / SUSPENSION / BRAKES

Front Suspension 27.0mm leading-axle Showa fork; 5.5-inch travel
Rear Suspension Pro-Link Showa single-shock; 4.3-inch travel
Front Brakes Drum
Front Tire Drum
Rear Tire 2.50-16
Rear Tire 3.60-14

DIMENSION

Rake 28.02 degrees
Trail 74.0mm (2.9 inches)
Wheelbase 47.6 inches
Seat Height 28.9 inches
Ground Clearance 8.6 inches
Dry Weight 154.0 pounds
Fuel Capacity 1.5 gallons, including 0.3-gallon reserve

OTHER

Model ID CRF80F
Warranty 6 months
Carrier Red

2005 CRF80F

Engine

Engine Type 80cc air-cooled single-cylinder four-stroke
Bore and Stroke 47.5mm x 45.0mm
Compression Ratio 9.7:1
Spark plug CR7HSA
Plug gap .028
Valve Train SOHC; two-valve
Fuel Delivery 20.0mm piston-valve
Ignition CDI

DRIVETRAIN

Transmission Five-speed
Final Drive #420 chain x 110
Front sprocket 14T
Rear sprocket 46T

CHASSIS / SUSPENSION / BRAKES

Front Suspension 27.0mm leading-axle Showa fork; 5.5-inch travel
Rear Suspension Pro-Link Showa single-shock; 4.3-inch travel
Front Brakes Drum
Front Tire Drum
Rear Tire 2.50-16
Rear Tire 3.60-14

DIMENSION

Rake 28.02 degrees
Trail 74.0mm (2.9 inches)
Wheelbase 47.6 inches
Seat Height 28.9 inches
Ground Clearance 8.6 inches
Dry Weight 154.0 pounds
Fuel Capacity 1.5 gallons, including 0.3-gallon reserve

OTHER

Model ID CRF80F
Warranty 6 months
Carrier Red

2006 CRF80F

Engine

Engine Type 80cc air-cooled single-cylinder four-stroke
Bore and Stroke 47.5mm x 45.0mm
Compression Ratio 9.7:1
Spark plug CR7HSA
Plug gap .028
Valve Train SOHC; two-valve
Fuel Delivery 20.0mm piston-valve
Ignition CDI

DRIVETRAIN

Transmission Five-speed
Final Drive #420 chain x 110
Front sprocket 14T
Rear sprocket 46T

CHASSIS / SUSPENSION / BRAKES

Front Suspension 27.0mm leading-axle Showa fork; 5.5-inch travel
Rear Suspension Pro-Link Showa single-shock; 4.3-inch travel
Front Brakes Drum
Front Tire Drum
Rear Tire 2.50-16
Rear Tire 3.60-14

DIMENSION

Rake 28.02 degrees
Trail 74.0mm (2.9 inches)
Wheelbase 47.6 inches
Seat Height 28.9 inches
Ground Clearance 8.6 inches
Dry Weight 154.0 pounds
Fuel Capacity 1.5 gallons, including 0.3-gallon reserve

OTHER

Model ID CRF80F
Carrier Red

2007 CRF80F

OVERVIEW

  • What’s great about the CRF line-up is that there’s a model for each step along a young rider’s learning curve. Take the CRF80F. Loaded with big-bike performance features, like a manual clutch and five-speed gearbox, it’s the perfect machine for the rider who’s ready to move up to a serious off-road bike, but perhaps still too small for a CRF100F.

Engine

Engine Type 80cc air-cooled single-cylinder four-stroke
Bore and Stroke 47.5mm x 45.0mm
Compression Ratio 9.7:1
Spark plug CR7HSA
Plug gap .028
Valve Train SOHC; two-valve
Fuel Delivery 20.0mm piston-valve
Ignition CDI

DRIVETRAIN

Transmission Five-speed
Final Drive #420 chain x 110
Front sprocket 14T
Rear sprocket 46T

CHASSIS / SUSPENSION / BRAKES

Front Suspension 27.0mm leading-axle Showa fork; 5.5-inch travel
Rear Suspension Pro-Link Showa single-shock; 4.3-inch travel
Front Brakes Drum
Front Tire Drum
Rear Tire 2.50-16
Rear Tire 3.60-14

DIMENSION

Rake 28.02 degrees
Trail 74.0mm (2.9 inches)
Wheelbase 47.6 inches
Seat Height 28.9 inches
Ground Clearance 8.6 inches
Dry Weight 154.0 pounds
Fuel Capacity 1.5 gallons, including 0.3-gallon reserve

OTHER

Model ID CRF80F
Carrier Red

2008 CRF80F

OVERVIEW

  • Is your youngster ready to move up to the next level, where big-bike features — like five-speed shifting with a manual clutch — will help take them up to the next step of the off-road learning curve? Then check out the CRF80F, loaded with plenty of power, performance, and Honda’s legendary four-stroke reliability, making it the perfect tool for the young rider who’s ready to hone his or her off-road skills to a finer edge.



Engine

Engine Type 80cc air-cooled single-cylinder four-stroke
Bore and Stroke 47.5mm x 45.0mm
Compression Ratio 9.7:1
Spark plug CR7HSA
Plug gap .028
Valve Train SOHC; two-valve
Fuel Delivery 20.0mm piston-valve
Ignition CDI

DRIVETRAIN

Transmission Five-speed
Final Drive #420 chain x 110
Front sprocket 14T
Rear sprocket 46T

CHASSIS / SUSPENSION / BRAKES

Front Suspension 27.0mm leading-axle Showa fork; 5.5-inch travel
Rear Suspension Pro-Link Showa single-shock; 4.3-inch travel
Front Brakes Drum
Front Tire Drum
Rear Tire 2.50-16
Rear Tire 3.60-14

DIMENSION

Rake 28.02 degrees
Trail 74.0mm (2.9 inches)
Wheelbase 47.6 inches
Seat Height 28.9 inches
Ground Clearance 8.6 inches
Dry Weight N/A
Fuel Capacity 1.3 gallons, including 0.3-gallon reserve

OTHER

Model ID CRF80F
Carrier Red
Emissions Meets current CARB and EPA standards.
6 months warranty Coverage of defects in materials and workmanship

2009 CRF80F

Engine

Engine Type 80cc
Bore and Stroke 47.5mm x 45.0mm
Compression Ratio 9.7:1
Fuel System 20mm piston-valve carburator
Ignition CDI

DRIVETRAIN

Transmission Five-speed
Final Drive #420 chain x 110
Front sprocket N/A
Rear sprocket N/A

CHASSIS / SUSPENSION / BRAKES

Front Suspension 27.0mm leading-axle Showa fork; 5.5-inch travel
Rear Suspension Pro-Link Showa single-shock; 4.3-inch travel
Front Brakes Drum
Front Tire Drum
Rear Tire 2.50-16
Rear Tire 3.60-14

DIMENSION

Wheelbase 47.6 in.
Seat Height 28.9 inches
Dry Weight 163 lbs.
Fuel Capacity 1.3 gal.

OTHER

Price $2099
Carrier Red
Warranty 6 Months

2012 CRF80F

Engine

Engine Type Air-cooled single-cylinder four-stroke
Displacement 80 cc
Bore and Stroke 47.5 mm x 45 mm
Compression Ratio 9.7:1
Fuel Delivery
    • Canada: Single 18 mm piston-valve carburetor
    • US: 20mm piston-valve carburator
Ignition CD

DRIVETRAIN

Transmission Five-speed with manual clutch
Final Drive #420 chain x 110
Front sprocket 14T
Rear sprocket 46T

CHASSIS / SUSPENSION / BRAKES

Front Suspension 27 mm leading-axle Showa fork; 123 mm (5 in.) travel
Rear Suspension Pro-Link Showa single shock; 110 mm (4.3 in.) travel
Front Brakes Drum
Front Tire Drum
Rear Tire 2.50-16
Rear Tire 3.60-14

DIMENSION

Rake 28.02 degrees (Caster Angles)
Trail 74mm (2.9 inches)
Ground Clearance 218 mm (8.6 in.)
Wheelbase 1,209 mm (47.6 in.)
Seat Height 734 mm (28.9 in.)
Dry Weight 75 kg (165 lb) including required fluids and full tank of gas – ready to ride
Fuel Capacity 5 litres (1.3 GalUS), including 0.7-litre (0.3 Gal) reserve

OTHER

Price $2099
Carrier Red
Warranty 6 Months
