Engine
|
|
| Engine Type |
Air cooled, parallel twin cylinder, four stroke, SOHC, 3 valves per cylinder, 360� crankshaft and twin balance-shafts |
| Displacement |
447cc (27 cid) |
| Bore and Stroke |
75 X 50.6mm |
| Compression Ratio |
9.1:1 |
| Fuel Delivery |
Two 30mm Keihin CV |
| Ignition |
CDI |
| Starter |
Electric |
| Max Power |
45 hp 32.8 KW @ 9000 rpm |
Drivetrain
|
|
| Transmission |
6-speed |
| Clutch |
Wet, Multi-Plate |
| Final drive |
Chain |
CHASSIS / SUSPENSION / BRAKES
|
|
| Front Suspension |
Telescopic forks 124.5mm wheel travel |
| Rear Suspension |
Swing arm 97mm wheel travel |
| Front Brakes |
Single 272mm disc |
| Rear Brakes |
140mm Drum |
| Front Tire |
3.25-19 |
| Rear Tire |
120/90-18 |
DIMENSION
|
|
| Seat height |
790 mm (31.1 in.) |
| Fuel capacity |
13 Litres (3.4 Gal) |
| Dry weight |
180 kg (396 lb) |
OTHER
|
|
| Colors |
- Pleiades Silver Metallic
- Black
|
