2022 Honda CBR500R [Specs, Features, Photos]

2022 Honda CBR500R

2022 Honda CBR500R: Middle Ground Zero

The CBR500R prides itself as being the perfect mid-way bike, bridging the ever-increasing gap between standard and supersport motorcycles. This model takes a very similar approach to ergonomics and overall bike attitude to its bigger brother, the CBR650R, making it the perfect in-between motorcycle in Honda’s 2022 lineup.

At first glance, the CBR500R looks like a traditional Japanese supersport bike, but much like the Kawasaki Ninja 650, Honda has cleverly hidden an upright seating position and comfortable ergonomics perfect for commuting around town.

The main selling point for the CBR500R is the fact that it is ridable with an A2 license for riders in Europe, allowing riders to get a similar experience to that found with the CBR650R without having to take the jump in licencing.

2022 brings Showa 41mm Separate Function Fork Big Piston (SFF-BP) USD forks, dual disk brakes in the front, and a shift in the overall weight of the bike to improve handling and accuracy. Along with these minor changes, the CBR500R will also be available in a new for 2022 Gunpower Black Metallic colorway.

The 2022 Honda CBR500R starts at $7,199 USD / $8,149 CAD

On this page: we’ve curated specs, features, news, photos/videos, etc. so you can read up on the new 2022 Honda CBR500R in one place.

2022 Honda CBR500R


Model Overview

General Info

  • Price: $7,199 USD / $8,149 CAD
  • Key Features:
    • Standard ABS
    • 471cc Engine
    • Slipper clutch
    • New color option for 2022

Main Specs

  • Engine: 471cc Parallel Twin
  • Power: 50 BHP
  • Torque: 31.7 lbft
  • Wet Weight: 423 lbs (192 kg)
  • Seat Height: 30.9 inches (785 mm) at lowest point

Competitors

2022 Honda CBR500R


2022 Honda CBR500R Specifications

From Honda

ENGINE

Engine 471cc Liquid-Cooled Parallel-Twin
Power 50 BHP
Bore x Stroke 67.0mm x 66.8mm
Compression Ratio 10.7:1
Induction PGM-FI with 34mm throttle bodies
Starter
Valve Train DOHC; four valves per cylinder

DRIVETRAIN

Clutch
Transmission Six-speed
Final Drive O-ring-sealed chain; 15T/41T

CHASSIS

Suspension Front 41mm Showa SFF-BP fork; 4.3 inches of travel
Suspension Rear Pro-Link® single shock with nine-position spring preload adjustability; 4.7 inches travel
Brakes Front Twin four-piston calipers with 296mm discs; ABS
Brakes Rear Single-caliper 240mm disc; ABS
Tires Front 120/70R-17
Tires Rear 160/60-17
Fuel Tank Capacity 4.5 gallons
Color Grand Prix Red, Sword Silver Metallic

ELECTRICAL

Ignition Full transistorized
Spark Plugs
Headlight
Tail Light

DIMENSIONS

Overall Length
Ground Clearance
Trail 4.0 inches
Wheelbase 55.5 inches
Rake (Caster Angle) 25.5°
Seat Height 31.1 inches
Curb Weight 423 pounds (Includes all standard equipment, required fluids and full tank of fuel-ready to ride)

WARRANTY

Warranty Transferable, unlimited-mileage limited warranty
Extension Extended coverage available with a HondaCare Protection Plan®

2022 Honda CBR500R


2022 Honda CBR500R Features

PERFORMANCE

DOHC TWIN-CYLINDER ENGINE

Honda twins are famous for their versatility, and the CBR500R’s engine is one of our best ever. With good low-end horsepower and torque, the parallel twin offers accessible performance across all RPM ranges.
PROGRAMMED FUEL INJECTION (PGM-FI)

PGM-FI continuously monitors several variables to ensure the correct fuel mixture is delivered for the existing riding and atmospheric conditions, ensuring a crisp throttle response throughout a wide variety of riding. Programed fuel injectors increase power and torque in the midrange.
STAINLESS STEEL EXHAUST

With a dual-outlet muffler that you need to hear for yourself, this beautifully polished stainless-steel exhaust is integrated with the rear footpeg set for clean, functional design. The exhaust tucks in tight for better mass centralization (and consequently better handling).

STYLE

SUPERSPORT STYLING

The CBR500R’s aggressive styling comes with two great color options (Grand Prix Red and Sword Silver Metallic), that keep it right at the front of the pack in terms of eye-appeal. The aerodynamic bodywork also provides significant advantages in air management for added rider comfort, along with a low drag coefficient and effective cooling.

ENGINEERING

ANTI-LOCK BRAKING SYSTEM (ABS)

Standard equipment on every 2022 CBR500R, anti-lock brakes (ABS) help you make confident stops under less-than-ideal conditions.
DIGITAL INSTRUMENTATION

An LCD screen features a digital speedometer and tachometer and more, including a clock, odometer, trip meter, real-time and average fuel consumption meters, and illuminated engine diagnostic indicators.
DISC BRAKES

New for 2022, the CBR500R now features twin front disc brakes. The two 296mm discs are gripped by twin four-piston radial-mount calipers. Together with the 240mm rear disc brake, you get strong, predictable stopping power. The front-brake lever is also adjustable for a perfect fit.
LED HEADLIGHTS

The CBR500R sports a pair of powerful LED headlights. They’re small and light, throw out an amazing amount of illumination, and feature a stylish shape. The design also increases the engine’s intake airflow.
SLIPPER/ASSIST CLUTCH

The slipper/assist clutch lets us lighten up the clutch-lever effort by 45 percent compared to previous systems, but automatically locks up tight when you release it.
SMOOTHER TRANSMISSION

Our engineers profiled the shift dogs in the transmission to help you get smoother shifts every time. You’ll never see these parts, but you’ll feel their effects.
NEW, LIGHTER SWINGARM

For 2022, the CBR500R gets a new swingarm that’s over two pounds lighter than the previous generation’s, but just as strong. It’s one of the reasons the entire Honda 500 family handles so well.

HANDLING

STEEL-TUBE FRAME

A motorcycle’s frame is the basis for its handling. The CBR500R’s diamond-shaped 35mm steel-tube mainframe ties to the engine with four mounts, offering a rock-solid foundation for a superior ride and handling.
UPSIDE-DOWN FORK

Probably the most significant change for 2022 is the upside-down fork on the CBR500R. The inverted design makes the front end much more rigid, for more precise steering input and feedback. The fork itself is a 41mm Showa SFF-BP design—one of the best in its class.
NEW CAST WHEELS

Strong and stylish, the CBR500R’s aluminum wheels feature a new five-spoke design this year that’s lighter than our previous wheels. That improves handling, and lessens wheel inertia too.
PRO-LINK® REAR SUSPENSION

The CBR500R features special shock settings for improved ride comfort. Its sophisticated chassis uses Honda Pro-Link® rear suspension; the nine-stage adjustable preload and 4.7 inches of travel give you a comfortable ride over small bumps, while capably absorbing bigger bumps to increase riding comfort and handling.

COMFORT

STEP SEAT

The CBR500R offers a stepped two-piece seat with a low height. Perfect for around-town riding or winding roads, it also offers room for a passenger and is specially designed to fit a wide range of riders.
