Engine
|
|
| Engine Type |
Liquid-cooled 4-stroke 8-valve, SOHC parallel 2-cylinder |
| Bore and Stroke |
73 x 80mm |
| Valves |
Chain driven SOHC, 4 valves per cylinder |
| Displacement |
670cc |
| Compression Ratio |
10.7:1 |
| Fuel Delivery |
PGM-FI electronic fuel injection |
| Ignition System |
Computer-controlled digital transistorised with electronic advance |
| Max. Torque |
62Nm/4,750min-1 95/1/EC |
| Max. Power Outpu |
38.1kW/6,250min-1 95/1/EC |
DRIVETRAIN
|
|
| Transmission |
6-speed Dual Clutch Transmission |
| Final Drive |
Chain |
| Clutch |
Wet, multiplate hydraulic 2-clutch |
| Clutch Operation |
Push button – D mode/S mode/Manual mode |
| Front Wheels |
multi-spoke cast aluminium 17M/C x MT3.5 |
| Rear Wheels |
multi-spoke cast aluminium 17M/C x MT3.5 |
CHASSIS / SUSPENSION / BRAKES
|
|
| Frame type |
Diamond; steel pipe |
| Front Suspension |
41mm telescopic fork, 153.5mm (6 in.) travel |
| Rear Suspension |
Monoshock damper, Pro-Link® swingarm, 150mm (5.9 in.) travel |
| Front Tire |
120/70-ZR17M/C (58W) |
| Rear Tire |
160/60-ZR17M/C (69W) |
| Front Brakes |
320mm single wave/wavy hydraulic disc with 2-piston caliper and sintered metal pads |
| Rear Brakes |
40 single wave/wavy hydraulic disc with single-piston caliper and sintered metal pads |
DIMENSION
|
|
| Rake/trail |
27.0 degrees/110.0mm (4.3 inches) |
| Wheelbase |
1525mm (60 inches) |
| Overall Length |
2195mm (86.4 inches) |
| Overall Width |
790mm (31.1 inches) |
| Overall Height |
1440mm (56.7 inches) |
| Curb Weight |
238 kg (524 lb) |
| Seat Height |
790mm (31.1 inches) |
| Ground Clearance |
135mm (5.3 inches) |
| Fuel Tank Capacity |
14.1 Litres (3.7 GalUS) |
OTHER
|
|
| Fuel Consumption |
3.6 L/100km (17.3 miles/litre) (65.5 mpgUS) (78.6 mpg-Imp) |
