Engine
|
|
| Engine Type |
Liquid-cooled 4-stroke Unicam 16-valve 76° V4 |
| Engine Displacement |
1,237cc |
| Bore and Stroke |
81 x 60mm |
| Compression Ratio |
12:1 |
| Ignition Timing |
8.4° BTDC (idle speed) |
| Fuel Delivery |
PGM-FI electronic fuel injection |
| Ignition |
Computer-controlled digital transistorised with electronic advance |
| Max. Power Output |
95kW/7,750min-1 (95/1/EC) |
| Max. Torque |
126Nm/6,500min-1 (95/1/EC) |
Drivetrain
|
|
| Transmission |
6-speed (DCT = D mode/S mode/Manual mode) |
| Clutch |
Wet multiplate (DCT = Wet multiplate, hydraulic 2-clutch) |
| Primary Reduction |
1.738 (73T / 42T) |
| Final Reduction |
2.699 (37/39 x 19/17 x 28/11) / DCT = 2.706 (39/41 x 19/17 x 28/11) |
| Final Drive |
Enclosed shaft |
| Front Wheels |
Tube less spoked 19 x MT2.5 |
| Rear Wheels |
Tube less spoked 17 x MT4 |
CHASSIS / SUSPENSION / BRAKES
|
|
| Frame type |
Diamond; aluminium twin-spar |
| Front Suspension: |
43mm inverted telescopic forks with hydraulic damping, preload and rebound damping adjustment |
| Rear Suspension |
Pro-Link with gas-charged damper, preload and stepless rebound damping adjustment |
| Front Tire Size |
110/80-R19 |
| Rear Tire Size |
150/70-R17 |
| Front Tire Pressure |
250kPa (36 psi) |
| Rear Tire Pressure |
290kPa (42 psi) |
| Front Brakes |
Dual 310mm disks, Combined ABS |
| Rear Brakes |
Single 276mm disk, Combined ABS |
DIMENSION
|
|
| Caster Angle |
28° |
| Trail |
107mm (4.2 inches) |
| Wheelbase |
1595mm (62.9 inches) |
| Overall Length |
2285mm (90 inches) |
| Overall Width: |
915mm (36 inches) |
| Overall Height |
1335mm (52.5 inches) |
| Seat Height |
850mm (33.5 inches) |
| Ground Clearance |
180mm (7.1 inches) |
| Curb Weight |
275 kg (604 lb) [Front: 132 kg (290 lb); Rear: 143 kg (315 lb)] |
| Fuel Tank Capacity |
21.5 Litres (5.7 |
OTHER
|
|
| Fuel Consumption |
6.2L/100km (37.9 mpg US) |
