2022 KTM 890 Duke R [Specs, Features, Photos]

2022 KTM 890 Duke R

2022 KTM 890 Duke R: The Radical Naked

Known as the ‘Super Scalpel,’ the 890 KTM Duke R is a naked bike from the Austrian brand’s 2022 lineup. This motorcycle stands out for its two-cylinder engine that produces 121 hp and 99 Nm of torque (the most powerful 2-cylinder engine in its segment). The engine is paired with a six-speed gearbox.

This bike is ideal for those seeking maximum performance, both on and off the track, going one step further than the standard KTM 890 Duke R, mainly thanks to a much faster and more aggressive steering geometry and Austrian-engineering.

The 2022 890 Duke R comes with the adjustable WP Apex suspensions, Brembo Stylem monobloc calipers, and discs, combined with an adjustable Brembo MCS pump and Michelin Powercup II hypersport tires.

Electronic highlights include cornering ABS and cornering MTC (motorcycle traction control). This 6D inertial measurement unit detects not only the lateral movements, forward and backward (pitch) of the motorcycle but also the rotation of the motorcycle on its vertical axis (yaw).

For 2022, the KTM 890 Duke R boasts a new livery called “Atlantic Blue”, similar to that of MotoGP KTM RC16 GP and, more recently, on the KTM 1290 SUPER DUKE R. The chassis remains in orange, characteristic of the ‘R’ models and now makes an even more striking contrast.

The 2022 KTM 890 Duke R starts at $12,399 USD / $14,406 CAD.

On this page: we’ve curated specs, features, news, photos/videos, etc. so you can read up on the new 2022 KTM 890 Duke R in one place.



2022 KTM 890 Duke R


Model Overview

General Info

  • Price:  $12,399 USD / $14,406 CAD
  • Key Features:
    • Powerful 121 hp twin-cylinder engine
    • WP APEX suspensions
    • Brembo Stylema brakes
    • Michelin Powercup II hypersport tires

Main Specs

  • Engine: 889 cc single-cylinder
  • Power: 121 hp (89 kW) at 9,500 rpm
  • Torque: 73 lb-ft (99 Nm) at 7,000 rpm
  • Wet Weight:  405 lbs (183 kg)
  • Seat Height: 32.8 in. (833 mm)

2022 KTM 890 Duke R


2022 KTM 890 Duke R Specifications

From KTM

ENGINE

Engine 889cc, 2-cylinder, 4-stroke, parallel twin
Power 121 hp
Bore x Stroke 90.7 mm x 68.8 mm
EMS Bosch EMS with RBW
Power in KW 89 kW
Starter Electric starter
Lubrication Forced oil lubrication with 2 oil pumps

DRIVETRAIN

Clutch PASC™ antihopping clutch, mechanically operated
Transmission 6-speed
Chain 520 X-Ring

CHASSIS

Suspension Front WP APEX 43
Suspension Rear WP APEX – Monoshock
Brakes Front 320 mm
Brakes Rear 240 mm
Tank capacity (approx.)
Color

ELECTRICAL

Ignition
Spark Plugs
Headlight LED
Tail Light LED

WARRANTY

Warranty
Extension

2022 KTM 890 Duke R


2022 KTM 890 Duke R Features

Engine

Developed from the same parallel twin that powers the KTM 790 DUKE, the KTM 890 DUKE R engine has been worked into a fire-breathing, high-performance midweight titan. With its increased bore and stroke, higher compression and higher max. RPM limit, the KTM 890 DUKE R churns out an impressive new level of horsepower and torque.

Engine case

The KTM 890 DUKE R features horizontally split, high pressure cast aluminum crankcases, allowing for reduced wall thickness and weight. A heavier crankshaft and flywheel setup also helps to pump up torque.

Injectors

Developed specifically for KTM by DELL’ORTO, new sensors in each throttle body measure the manifold pressure and adjust the mixture accordingly per cylinder, improving throttle response and smoothing out throttle action for more precise throttle inputs.

Frame

Just like the KTM 790 DUKE, the KTM 890 DUKE R’s handling characteristics are thanks to the dynamic, loadbearing design of the tubular chassis, which allows it to carve through twisty tracks and mountain passes with extreme responsiveness. Just like every other KTM R, the frame is painted orange to highlight its sporty credentials.

Subframe

The subframe is cast aluminum and houses the airbox. No plastic covers, no additional brackets – everything is cast into two connected pieces to reduce complexity and weight. The triangular shapes in the subframe allow for a stronger, stiffer construction.

Suspension

Adapted to suit the added power of the KTM 890 DUKE R but still retaining the signature DUKE agility, the adjustable suspension on the KTM 890 DUKE R has been fettled to be sportier with improved high-speed stability, while retaining real-world street riding comfort.

Swingarm

The die-cast, open-lattice swingarm is optimized for stiffness but features a steeper angle for increased stability as well as excellent flex characteristics. This makes the KTM 890 DUKE R every bit as sharp as you’d expect it to be.

Handlebar

The tapered aluminum handlebars are positioned flatter, lower and further forward to increase feeling from the front tire and give the KTM 890 DUKE R a racier riding position. Riders can also tailor their preferred reach with three rotational adjustments and 4 positions of fine-tuning on the triple clamp.

Bodywork

The KTM 890 DUKE R casts an intimidating shadow thanks to its menacing profile and ultrasharp lines. In the metal, however, it’s obvious that this DUKE means business. Compact proportions, loud graphics and a bright orange frame are all unapologetically KTM R.
