Honda VTX1800N Motorcycles


2005 VTX1800N



Engine

Engine Type 1795cc liquid-cooled 52-degree V-twin
Bore and Stroke 101mm x 112mm
Compression Ratio 9.0:1
Valve Train SOHC; three valves per cylinder
Fuel Delivery PGM-FI with automatic choke
Ignition Digital, two spark plugs per cylinder

Drivetrain

Transmission Five-speed
Final Drive Shaft

CHASSIS / SUSPENSION / BRAKES

Front Suspension 45mm inverted fork; 5.1 inches travel
Rear Suspension Dual shocks with five-position spring-preload adjustability; 3.9 inches travel
Front Brakes Dual 296mm discs with LBS three-piston calipers
Rear Brakes Single 316mm disc with LBS twin-piston caliper
Front Tires 150/80R-17 radial
Rear Tires 180/70R-16 radial

DIMENSION

Rake 32.0 degrees
Trail 163mm (6.4 inches)
Wheelbase 67.5 inches
Seat Height 27.3 inches
Dry Weight 756 lb
Fuel Capacity 5.3 gallons

OTHER

Colors
  • Colors:
  • Black
  • Candy Orange
  • Metallic Silver
  • Bright Blue Metallic
  • California version differs slightly due to emissions equipment.

2006 VTX1800N

Engine

Engine Type 1795cc liquid-cooled 52-degree V-twin
Bore and Stroke 101mm x 112mm
Compression Ratio 9.0:1
Valve Train SOHC; three valves per cylinder
Fuel Delivery Programmed Fuel Injection (PGM-FI) with automatic choke
Ignition Digital, two spark plugs per cylinder

Drivetrain

Transmission Five-speed
Final Drive Shaft

CHASSIS / SUSPENSION / BRAKES

Front Suspension 45.0 mm inverted fork; 5.1 inches travel
Rear Suspension Dual shocks with five-position spring-preload adjustability; 3.9 inches travel
Front Brakes Dual 296mm discs with LBS three-piston calipers
Rear Brakes Single 316mm disc with LBS twin-piston caliper
Front Tires 150/80R-17 radial
Rear Tires 180/70R-16 radial

DIMENSION

Rake 32.0 degrees
Trail 163mm (6.4 inches)
Wheelbase 67.5 inches
Seat Height 27.3 inches
Dry Weight 756 lb
Fuel Capacity 5.3 gallons

OTHER

Colors
  • Titanium
  • Black
  • Dark Red
Model ID VTX1800N1

2007 VTX1800N

Engine

Engine Type 1795cc liquid-cooled 52-degree V-twin
Bore and Stroke 101mm x 112mm
Compression Ratio 9.0:1
Valve Train SOHC; three valves per cylinder
Fuel Delivery Programmed Fuel Injection (PGM-FI) with automatic choke
Ignition Digital, two spark plugs per cylinder

Drivetrain

Transmission Five-speed
Final Drive Shaft

CHASSIS / SUSPENSION / BRAKES

Front Suspension 45.0 mm inverted fork; 5.1 inches travel
Rear Suspension Dual shocks with five-position spring-preload adjustability; 3.9 inches travel
Front Brakes Dual 296mm discs with LBS three-piston calipers
Rear Brakes Single 316mm disc with LBS twin-piston caliper
Front Tires 150/80R-17 radial
Rear Tires 180/70R-16 radial

DIMENSION

Rake 32.0 degrees
Trail 163mm (6.4 inches)
Wheelbase 67.5 inches
Seat Height 27.3 inches
Dry Weight 756 lb
Fuel Capacity 5.3 gallons

OTHER

Emissions Meets Current EPA standards. California version differs slightly due to emissions equipment.
Colors
  • Metallic Black
  • Metallic Black/Red Custom Art
  • Dark Red/Red Custom Art
Model ID VTX1800N1

2008 VTX1800N



Overview

  • Neo Retro might seem a contradiction in terms, but the VTX1800N is all that: stylish, head-turning, from its swooping fenders and straight-cut mufflers to the LED taillights and gorgeous cast aluminum wheels. Call it throwback beauty with a modern-day touch.
  • Flush-Mounted LED Brake & Taillights
  • Bullet-Style Turn Signals
  • Hot-Rod Retro Fender Style
Engine
Engine Type 1795cc liquid-cooled 52-degree V-twin
Bore and Stroke 101mm x 112mm
Compression Ratio 9.0:1
Valve Train SOHC; three valves per cylinder
Fuel Delivery PGM-FI with automatic choke
Ignition Digital, two spark plugs per cylinder

Drivetrain

Transmission Five-speed
Final Drive Shaft

CHASSIS / SUSPENSION / BRAKES

Front Suspension 45.0 mm inverted fork; 5.1 inches travel
Rear Suspension Dual shocks with five-position spring-preload adjustability; 3.9 inches travel
Front Brakes Dual 296mm discs with LBS three-piston calipers
Rear Brakes Single 316mm disc with LBS twin-piston caliper
Front Tires 150/80R-17 radial
Rear Tires 180/70R-16 radial

DIMENSION

Rake (Caster Angle) 32.0 degrees
Trail 163mm (6.4 inches)
Wheelbase 67.5 inches
Seat Height 27.3 inches
Dry Weight 804 pounds
Fuel Capacity 5.3 gallons

OTHER

Spec 1 Colors
  • Black
  • Dark Orange Metallic
Spec 2 Colors
    • Black/Black Custom Art
    • Dark Orange Metallic
  • Warranty One-year unlimited-mileage limited warranty; extended coverage available with a Honda Protection Plan.
