| Engine Type |
Liquid-cooled 4-stroke 16-valve DOHC inline-4 |
| Bore and Stroke |
67 x 42.5mm |
| Displacement |
599cm3 |
| Compression Ratio |
12.0 : 1 |
| Carburation |
Electronic fuel injection |
| Max. Power Output |
108 bhp at 12,500min |
| Max. Torque |
63Nm at 10,000 rpm |
| Ignition |
Computer-controlled digital transistorised with electronic advance and HISS |
| Starter |
Electric |
| Gearbox |
6-speed |
| Final Drive |
‘O’-Ring sealed chain |
| Length x Width x Height |
2,065 x 685 x 1,135mm (2,100 x 685 x 1,135mm ABS) |
| Wheelbase |
1,390mm (1,385 ABS)mm |
| Seat Height |
805mm |
| Ground Clearance |
135mm |
| Fuel Capacity |
18 litres (including 3.5 litre warning light reserve) |
| Dry Weight |
170kg |
| Wheels Front |
17 x MT3.50 hollow-section triple-spoke cast aluminium |
| Wheels Rear |
17 x MT5.50 hollow-section triple-spoke cast aluminium |
| Tires Front |
120/70 ZR17 (58W) |
| ires Rear |
180/55 ZR17 (73W) |
| Suspension Front |
43mm cartridge-type telescopic fork, 120mm axle travel |
| Suspension Rear |
Pro-Link with gas-charged remote reservoir damper, spring preload and compression and rebound damping, 120mm axle travel |
| Brakes Front |
296mm dual hydraulic disc with dual-opposed four-piston callipers, floating rotors and sintered metal pads |
| Brakes Rear |
220mm hydraulic disc with single-piston calliper and sintered metal pads |
